SS 304 Stainless Steel Wire Diamond Mesh Security Window Screen

Brand Name	FuHua		Place of Origin	China
Model Number	Stainless Steel Wire Mesh		Material	Stainless Steel Wire
Type	Other, Woven Mesh		Application	Other, Window Screen
Technique	Woven		Wire Diameter	0.6-0.9mm
Weave Style	Plain Weave

SS 304 Stainless Steel Wire Diamond Mesh Security Window Screen

Introduction:

Diamond wire mesh is a high-strength metal mesh woven with 304 or 316 stainless steel wire, which has been color powder coated to obtain a delicate appearance. Its own material determines that it has excellent rust and corrosion resistance, high strength, suitable for building mosquito prevention, anti-theft and decoration and other occasions.

Material:

304 stainless steel wire: American standard 304 stainless steel wire, corresponding to the national standard 06Cr19Ni10 (old brand 0Cr18Ni9), general purpose stainless steel wire, diamond mesh window screen using a wide range of materials.
316 stainless steel wire: American standard 316 stainless steel wire, corresponding to the national standard 06Cr17Ni12Mo2 (old brand 0Cr17Ni12Mo2), applicable to seawater and other strong corrosive environment pitting resistant materials, special industrial corrosive environment diamond mesh window screen selection.

Process:

Diamond mesh window screen adopts heavy-duty dense weaving process, tensile strength reaches 650N/mm2~750N/mm2, with high strength and light weight aluminum profiles to make the screen door and window with strong resistance to external damage; mesh number 10-14 range, mosquitoes shall not pass through in summer, accompanying you a good sleep.

Specifications:

The standard specification series of stainless steel wire diamond mesh window screens are:
1、FH-CS-SS-0.9/10: wire diameter 0.9mm, mesh number 10, aperture 1.64mm.
2、FH-CS-SS-0.8/11: wire diameter 0.8mm, mesh number 11, aperture 1.50mm.
3、FH-CS-SS-0.7/12：filament diameter 0.7mm, mesh number 12, aperture 1.41mm.
4、Stock standing mesh roll width 0.8m, 1.0m, 1.2m, 1.5m, length 30m, 50m, 100m.

5、Standard electrostatic spraying room, the average thickness of the coating range 0.05mm ~ 0.10mm. black, dark gray paint is always available, other colors need to be customized by the user to provide color plates.
