ACT VK37 Style 4 Cly Lpg /cng Rail Injection for Autogas CNG LPG GNV Injector Rail
- T/T Credit Card
You May Like
-
4cyl CNG/LPG Rail Injector Auto Engine Parts Cng Lpg Conversion Kits for Sale CNG Rail Injector
-
Electric Car Conversion Kit Lpg Cng Injector Rail for 4 Cylinders Gas System for Car Injector Rail
-
Injector Rail 4 Cylinder 2 Ohm CNG LPG Conversion Kit Auto Gas Injection Nozzles Adjustable GNV Gas LP
-
LPG CNG Injector Rail Nozzles 4 Cylinder 2 Ohm 3 Ohm Dual Fuel Conversion GNV GLP Gas Natural Gas LP Auto Gas Injection
-
CNG LPG Injector Rail 4 Nozzles Rail de Inyectores Gas Natural 4 Cylinders 3 Ohm
-
LPG Nozzle Injector Rail Auto Gas Conversion Kit 2 Ohm 4 Cylinders
Product Description

ACT VK37 style 4 cly lpg /cng rail injection for autogas CNG LPG GNV injector rail
Brief Introduction
Injector rail is one part of gas engine air intake system ,comprised of a group of jet nozzles, temperature and pressure sensors, spray rail body, outlet nozzles and other components
In the different conditions of the engine, according to the ECU control strategy ECU calculated the injection timing and pulse width (jet volume) ], compressed natural gas injected into the gas rationing rail or cylinder.


SPECIFICATIONS FOR ACT-V4D Injector Rail | ||||||
Product details | Regulated media | CNG | LPG | |||
Resistance | 3 ohm | 2 ohm | ||||
Material | Aluminum Alloy | |||||
Main parameters | Opening time | 3 ms | 2.5 ms | |||
Closing time | 2 ms | 1.8 ms | ||||
Working pressure | 0.5~2.5 bar | 0.5~2.5 bar | ||||
Maximum pressure | 4.5 bar | 4.5 bar | ||||
Under pressure | 8 bar | 8 bar | ||||
Voltage | DC12V±10% | DC12V±10% | ||||
Nozzle diameter | φ1.5 | φ1.5 | ||||
Inlet connector | Inner diameter of rubber hose φ10 | |||||
Outlet connector | Inner diameter of rubber hose φ16 | |||||
Working temperature | -20℃ + 120 ℃ | |||||
Package details | 30 Pieces / carton | 20KG | 0.030 CBM | |||
40 Pieces / carton | 26 KG | 0.035 CBM | ||||
50 Pieces / carton | 33 KG | 0.040 CBM | ||||












HOT SALE
4 CYLINDER ECU KITS(OEM)

HOT SALE
4 CYLINDER MP36 ECU KITS

HOT SALE
568 CYLINDER ECU KITS

HOT SALE
4 Cylinder LPG KITS

HOT SALE
4 Cylinder CNG KITS








Until now, we have participated in well-known foreign exhibitions as scheduled. Such as SUFGAS in Russia , Peru FIGAS in Peru , ALTFUELS in Mexico etc . ,
We have sold our products more than 60 countries around the world . We are committed to promoting our products to the world , leads green world , better environment !

technical support services-after sales.
Welcome to visit ACT ?。?! We are looking forward to cooperating with you sincerely .


Packaging
A:Common Packing: Plastic bag + Label + Inner Box+Export Carton
B:Customized Packing: OEM Label, Inner Box,etc.
C:Package will be processed after all the tests finished.
Transportation
(1)By sea,by air,or by express (TNT,Fedex,UPS,DHL,EMS etc);
(2)We can provide freight services or deliver the goods to your designated forwarder.
(3)We support most inlan dport, such as Shanghai ,Guangdong .

Why choose us?.................................................................
1)Top Quality. Every product is made through strictly production process and quality testing, which has pass the test of BV,ISO, CE and GOST, and been accepted by clients spreading over 43 countries even including Italy and Poland.
2)2-year Warranty. All products enjoying 2 years free of equipment maintainence warranty.
3)Free Sample. If you order a set of products for testing, we will return the freight to you from your next normal order;if you order a component for testing, we will return the sample charge to you.
4)Cost Saving. We provide long-life, shock-resistant autogas equipment with excellent quality and better performance, resulting in cost saving.
5)Quick Delivery. We promise to ship your goods with 3 days after confirming your order, or we would like to return your payment if you asked.
Can your factory supply OEM serive?.........................................
Yes, we can. Send us the sample or the detailed speicifications of the products you want to clone →calculate the cost of opening model →start to produce the sample for testing →continue to produce according to your feedback.
What's your MOQ, payment terms?............................................
Our MOQ :1 piece for sample order,5 pieces for normal order.
Our payment terms: T/T, D/P, L/C, Paypal, Westernunion.
