Gas Assisted Injection Molding

Feman Tooling, plastic molding company China, is an injection mold China maker specializes in plastic & die casting mold design and building, who offers full-service custom injection molding including design, prototype samples making, tool building, revision & modification, accessory JIG & Fixture, plastic mold production up to 250T capacity and precision components making.We provide custom plastic injection molding China, custom molded plastic parts and so on.The plastic injection price is reasonable,if you want buy affordable injection molding, please contact us anytime you free.

Gas assist molding, also known as gas injection (injection) molding, is a new gas injection moulding process. It is one of the most important developments in the injection molding industry since the advent of reciprocating screw injection machines. Gas-assisted injection molding process is an extension of injection molding. It is developed on the basis of injection molding technology and structural foam injection molding. it can also be considered as a composite of injection molding and hollow molding. In this sense, it can also be called "Hollow injection molding". The principle is to replace the resin pressure in the cavity with a relatively low-pressure gas during the pressure holding phase of the original injection molding. Gas-assisted injection can be achieved by simply adding an air supply device to the existing injection molding machine. The gas supply device is composed of an air pump, a high-pressure gas generating device, a gas control device, and a gas nozzle. The gas control device uses a special compressor to continuously supply gas, and is controlled by an electronic control valve to keep the pressure constant. There are usually 3 levels of pressure. A set of gas control device can be equipped with multiple injection molding machines.To achieve this, whole gas injectino moulding process required closely connections.

The gas generally used is nitrogen. Gas pressure and gas purity are determined by the shape of the molding material and product. The pressure is generally 5 ~ 32MPa, the highest is 40MPa.
