Fully Automatic Toilet Tissue Paper Making Machine for Sale
- T/T Credit Card
You May Like
-
New Technology Crescent Former Toilet Tissue Paper Making Machine
-
Full Automatic Toilet Tissue Paper Making Machine Production Line
-
Automatic Mini Toilet and Towel Rewinder Good Quality Small Machine to Make Toilet Paper Production Line
-
New Condition High Quality Toilet Tissue Hygienic Paper Making Machine/slitting and Rewinding Machine
-
Automatic Processing Embossed Rewinder Toilet Paper Roll Equipment Machine
-
High Quality Toilet Tissue Hygienic Paper Making Machine
Product Description
Automatic Wrapper Type High Speed Toilet Paper /Maxi Roll Rewinding Machine is for toilet paper roll/maxiroll processing. Machine have core feeding unit. Raw material from jumbo roll after full embossing or edge embossing, then perforation, end cutting and spray the tail glue become a log. Then it can working with cutting machine and packing machine to become the finished products. The machine is controlled by PLC, people operate it through touch screen, the whole process is automatic, easy to operate, lower the man cost. And Our machine can special-made according to clients' requirements.
Functions and Features --- Wall Type Automatic Rewinding Machine
1.This machine is for making toilet paper rolls, the whole structure is wall-type, which make machine running stable at high speed, and noiseless.
2. Perforation distance is adjustable to meet different distance needs.
3. Automatic core feeding system, automatic pushing the log after rewinding, then rewinding the new log again.
4. Automatic edge-trimming, glue spraying and sealing synchronously in one time. Leaving 10-18mm tail, easy to rewind again, so reducing shortcut waste and save the cost.
5. Adopts international advanced PLC programmable controlling technique, man-machine interface operation, data set and parametric fault shows on touch screen.
6. Adopts 4 pieces high Precision spiral knives, low noise, clear perforation, adopt gearbox to have bigger range.
7. Two wall type back stands, pneumatic lifting system, with wide driving flat belts; each jumbo roll can be adjusted independently.
8. Adopt jogging switches for wearing the paper, easy and safe to operate.
Video Link: https://youtu.be/GK44fR9n5tI
Full automatic maxi roll and small toilet paper rewinding machine | ||||||||
Jumbo Roll Max Width | 2800mm (Other size can be specified) | |||||||
Jumbo Roll Diameter | Φ1200mm(Other size can be specified) | |||||||
Jumbo Roll Inner Diameter | 3inches(76.2mm) (Other size can be specified) | |||||||
Perforation Distance | 4 anvil Blades(115mm)(Other size can be specified) | |||||||
Finished Product Diameter | Φ80~φ280mm | |||||||
Finished Product Core Diameter | φ38~φ76mm | |||||||
Production Speed | 0~230m/min | |||||||
Program Controller | PLC(DELTA OR INVT need to confirm) | |||||||
Unwind Stands | 1 or 3 Stands(Need to be specified) | |||||||
Pneumatic System | 3HP Air Compressor, Minimum Pressure: 5kg/cm 2Pa(Provide by user) | |||||||
Main Power | 15KW 380V 50HZ | |||||||
Dimension | 7000*4000*1900(L*W*H) | |||||||
Weight | About 7T | |||||||
Edge-Line Embossing | Steel to steel (Pneumatic Control) | |||||||
Full Embossment | Steel to rubber | |||||||
The machine will be packed in Wooden Case.
Spraying antirust oil on machine surface and cover PE film,then packed by seaworthy Export Packing
Wooden Case, ensure that the goods will safely arrive at the erection or construction site without any
damage.
1) Toilet Paper Machine (1.2m--2.8m width of parent roll, Customize Service)
2) Roll Kitchen Paper Towel Machine (1.2m--2.8m width of parent roll, Customize Service)
3) Facial Tissue Machine (2-8 output lanes)
4 )Napkin Paper machine(L-fold, 1/4-fold, 1/6-fold, 1/8-fold and other multi-fold type)
5) Hand Towel Paper Machine(C-fold, V-fold and N/Z fold type)
6) Pocket Tissue Machine(mini and standard size)
7) All kinds of Tissue Paper Cutting and Packing Machine
8) Another Household Paper Equipments and Production Line.
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 60-90 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
