VSA 200414 N 503.3x342x56mm Slewing Ball Bearing With External Teeth
- SHANGHAI
- T/T
- 30 days
You May Like
-
Slewing Ring VSA 200544 N 640.3x472x56mm VSA Turntable Bearing Series
-
Offer VSA 200644 N Slewing Ball Bearing 742.3X572X56mm for Conveyor Booms
-
VSA 200744 N 838.1x672x56mm Slewing Ball Bearing for Bucket Wheel Excavators Machine
-
VSA 200844 N 950.1x772x56mm Slewing Bearing for Indexing Tables Machine
-
Handling Systems Use VSA 200944 N 1046.1x872x56mm Slewing Ball Bearing
-
VSA 201094 N Slewing Ring With External Teeth 1198.1x1022x56mm for Ladle Turrets
Product Details
| Brand Name | JHB | Place of Origin | China | |
| Model Number | VSA 200414 N | Feature | Four Point Contact | |
| Seals Type | doulbe seal | Outside Diameter | 503.3, | |
| Bore Size | 342, | Gear Options | Nongeared |
Product Description
VSA 200414 N 503.3x342x56mm slewing ball bearing with external teeth
VSA 200414 N slewing bearing is composed of two seat rings. It has compact structure, light weight, and four-point contact between steel ball and arc raceway. It can bear axial force, radial force and overturning moment at the same time. The construction machinery of rotary conveyor, welding manipulator, small and medium-sized crane and excavator can be selected. The outer diameter:503.3mm,Inner diameter:342mm,Height:56mm, It is the light series bearing structure with internal teeth.
Description | VSA 200414 N slewing ball bearing |
Dimension(ODXIDXH) | 503.3x342x56mm |
Outer diameter(OD) | 503.3 mm |
Inner diameter(ID) | 342 mm |
Width/Height/(H) | 56 mm |
weight | 31kgs |
Material | 42CrMo, 50Mn |
Rolling | LYC ball |
Teeth data | |
do | 495mm |
m | 5 |
Teeth number | 99 |
Package | Inside package: plastic film + kraft paper + blue tape; Outside package: standard export free-fumigation wooden case. |
The delivery time | 20-30 days |
Service | Technology communicate with engineer, and if you need the assembly drawing,we can send to you |
