Handheld Fiber Laser Welder Stainless Steel Laser Welding Machine Stainless Steel

1. Handheld welding head is equipped with 1000 watt fiber laser, flexible, enabling outdoor welding.

2. Fast welding speed, 2~10 times faster than traditional welding.

3. The welding seam smooth and beautiful, large depth, small taper, don’t need polish, save time.

4. No deformation or welding scar, firm welding of the workpiece.

5. Laser welding has less consumables, low energy consumption and long service life.

6. Safety, easy operation and more environmentally friendly.

Single Module Fiber Laser generator with 1000 watts laser power

The advantage of laser welding wobble head:

1. The process that the conventional head can not complete ,the wobble head only needs to use about 70% of the power, so that the cost of the laser can be saved;

2. Wobble welding back and forth through the galvanometer motor, so that the bubbles with large impurities can reduce bubbles, frying, splashing, etc;

3. In the case of irregular gaps, the requirements for the fixture can be reduced.

The conventional oscillating head welding gap is generally 0.2 mm, and light exceeding this width directly passes through. The width of the gap that can be welded by the oscillating head can reach 0.5mm,but the conventional welding head can only be welded to 0.2mm. There is no galvanometer motor in the welding head, so there is no swing. The welding effect is not good, the welding process is limited.

Fiber laser welding wobble head

Water-cooling system

1. The integrated water cooler is more efficient for the welding head and laser cooling;

2. The integrated water cooling design also saves the layout space and freight cost for the customer;

3. Filters are uniformly installed on the chiller, which is safe, environmentally friendly, energy-saving and durable, stable working performance and long service life.

Package:

1.Anti-collision package edge: All parts of the machine are covered with some soft materials, mainly the use of pearl wool

2. Fumigation wooden box: Our wooden box is fumigated, do not need to check the wood, saving the transport time.

3.Whole film packaging machine: Avoid all damage that may occur during delivery. Then we will cover the plastic package tightly

to ensure that the soft material is covered intact, also avoiding water and rust. The outermost is a wooden box with a fixed template.

4. Wooden box at the bottom of a solid iron socket for easy handling

Three years warranty for the machine. English technical to door service.

5.We have three modes of transportation for you to choose:by sea, by land and by air.
