Home > Products > Hot products > Hot Runner Spiral Coil Heater
Hot Runner Spiral Coil Heater
                            US$ 5 - 25
                                                            / Piece


                                                5 Pieces(Min. Order)

                    - Shanghai for Spiral Coil Heater
 - T/T Credit Card

You May Like
-


Electric Air Industrial Heater Fin Tube Heater For Heat Exchanger
 -


Immersion Water Heater Element/ Immersion Flanged Heater for Water
 -


Flexible Silicone Heater Electric Gas Cylinder Heater
 -


Stainless Steel 304 Tube 10mm Waterproof Cartridge Heater
 -


Brass Tube Coil Heater For Injection Mould
 -


High Temperature Furnace MoSi2 Heating Element

Product Details
| Brand Name | Yuheng | Place of Origin | Jiangsu, China | |
| Type | Air Heater | Certification | CE ROHS | |
| Warranty | 1 Year, 1 year | |||
| Weight | 0.3kg/pcs | Dimension(L*W*H) | Custom Size | |
| Condition | New | Voltage | 220-380v | |
| Power Source | Electric |
Product Description
Description
Yuheng Spiral Coil Heater is compacted for faster and efficient heat transfer. Generally the long 20-3000mm, spring heating ring external using high-quality Ni-Cr steel tube, the internal use of high purity magnesium oxide, high-temperature resistance wire.
With high working temperature, fast heating,uniform heating precision, long service life, can be automatically controlled area, high thermal conduction, while internal heating material damage, external can be reused. The heaters are annealed to acquire malleability for bending into any shape. Hot runner heaters with built-in thermocouple are also available..
Sheath Material  | Cr Ni-Steel  | Thermocouple  | J-type(standard); K-type  |
Insulation Material  | MgO  | Length Tolerance(straight)  | 5%  |
Resistance Wire  | NiCr 80-20  | Wattage Tolerance  | 5%  |
Thermocouple  | J-type; K-type  | Resistance Tolerance  | 5%  |
Max. Sheath Temperature  | 650°C  | Unheated Length  | 35mm(standard)  |
Die Electrical Strength  | 800V A/C  | Dimensional Tolerance  | Coil I.D + 0.1~0.2mm  |
Insulation  | >5MW  | Coil length +1mm  |
Product Show






How to order?
pls provide these information:
1.Size(L,ID,L1,L2,D,L3)
2.Vottage and Wattage
3.
4.Quatity
If you have other question,pls contact our.




Related Products
Product Application
Plastics:  | Electronics:  |  Paper:  |
1.Thermoforming  | 1.Preheat PCBs  | 1.Speed drying coated paper  |
2.Vacuum forming  | 2. IR reflow ovens for SMT  | 2.Adhesive activation  |
3. Curing extruded parts  | ||
4.Drying Ceramic  | ||
5. Laminating  |
Textiles:  | Ceramic:  | Thin Film Deposition:  |
1.Drying dyed/printed fabric  | Drying glazes/pigments  | Vacuum coating substrates  |
2.Curing latex coatings  |
Vacuum coating substrates  |  Food:  | Printing:  |
1. Heating bonded/painted/plastic coated components  | 1.Warming  | Ink drying  |
2.Drying same components  | 2.Baking  |
Paint:  |  Packaging:  | Paper:  |
1.Drying lacquers/finishes  |  1.Heat shrinkForming  | 1.Speed drying coated  |
2.Baking lacquers/finishes  | 2.Forming  | 2.Adhesive activation  |




After Sales Service


1. Package tracking
2. One year guarantee
3. Technical support
4. 12 hours wking time
5. Discount for reorder
6. Replacements for quality problems
7. Confidentiality of customer information
