Ampoule Leak Sterilizer
- Shanghai
- T/T Credit Card
You May Like
-
DMH Series Purification Type Double Door High Temperature Sterilizing Oven
-
RXH Hot Air Oven Dryer Machine
-
RXH-B Series Hot Air Dryer Oven Machine
-
RXH-B Hot Air Drying Oven Industrial Price
-
RXH-B-I Hot Air Oven Drier Dryer Oven Machine
-
RXH Series Medical Hot Air Circulation Drying Oven Hot Air Circulating Drying Oven
Product Details
| Brand Name | SPM | Place of Origin | Shanghai, China | |
| Condition | New |
Product Description
Ampoule Leak Sterilizer Specifications
National patent sealing technology
GMP confirmation
PLC+touch screen control
This series is a kind of high-performance and high-intelligence equipment for sterilizing,leak detecting and cleaning,which adopts colorful touching screen and PLC,applicable to treating of ampoule,oral medicine, small infusion bottle,etc.After sterilization,by means of vacuum or vacuump plus water,the detecting rate of waster is assured to be 100%.Finally washing treatment is carried out with clean water to ensure surface of bottle clean and uncontaminated.
Main Parameters & Utilities:
Design pressure | 0.245Mpa | Vacunm | -0.095Mpa |
Working Pressure | 0.22Mpa | Steam Source Pressure | 0.4-0.6Mpa |
Design Temperature | 139°C | Water Source Pressure | 0.1-0.3Mpa |
Working Temperature | 134°C | Compressed Air Pressure | 0.5-0.7Mpa |
Heat Equilibrium | ≤±1°C |
|
Structure&Capability&Characteristics
·The boxis designed,produced and tested strictly according to the “teel Pressure Viessel”
·National patent sealing technology of inner gas
·National patent door interlock
·Reliable and stable micro-computer PLC+touch screen control,advanced function for recording, printing and storing
·Elegant stainless steel decorate cover
·The heat preservation layer is made by polyurethane material and pearl rock wool
·The GMP confirmation access is fixed on the equipment
·Unique spraying cooling device
Size & Utilities
Model | Overall Dimensions L*W*H(mm) | Chamber Size L*W*H(mm) |
AM-0.3 | 1195*1220*1720 | 1000*600*600 |
AM-0.6 | 1245*1300*1880 | 1050*180*850 |
AM-1.2 | 1695*1370*1960 | 1500*750*1100 |
AM-1.8 | 2445*1370*1960 | 2250*750*1100 |
AM-2.5 | 3195*1370*1960 | 3000*750*1100 |
AM-5.0 | 3635*1800*2200 | 3400*1000*1500 |
Main Parameters and Utilities
Design Pressure | 0.245Mpa |
Working Pressure | 0.22Mpa |
Design Temperature | 139°C |
Working Temperature | 134°C |
Heat equilibrium | ≤±1°C |
Vacuum | 0.095Mpa |
Steam Pressure | 0.4-0.6Mpa |
Water Pressure | 0.1-0.3Mpa |
Compressed Air Pressure | 0.5-0.7Mpa |
Loading
Model | 1ml | 2ml | 5ml | 10ml |
AM-0.3 | 37440 | 26100 | 10000 | 6800 |
AM-0.6 | 74880 | 52224 | 20160 | 13680 |
AM-1.2 | 127816 | 81664 | 33984 | 22400 |
AM-1.8 | 191724 | 122496 | 50976 | 33600 |
AM-2.5 | 255632 | 163328 | 67968 | 44800 |
AM-5.0 | 605568 | 380160 | 169344 | 98208 |
