Product Details
| Place of Origin | Jiangsu, China | Certification | CE& ISO9001& Bundersrepublik deutschland patents | |
| Dimension(L*W*H) | 11.5*9*6.9m | Voltage | 380V/3PH/50HZ | |
| Condition | New |
Product Description
palettes en plastique pour le bloc de briques fais
Product name: Fully automatic tie-barless extrusion blow molding machine(Accumulator) TDB-1200L
Extrusion blow molding machine technical specification:
|
Model |
|
TDB-1200L |
|
Station |
|
Single station |
|
Max. Product Volume |
(L) |
1200L |
|
Dry cycle |
(pc/h) |
30 |
|
Screw Diameter |
(mm) |
120*2 |
|
Screw L/D ratio |
(L/D) |
32 |
|
Screw drive power |
(KW) |
132*2 |
|
Screw heating capacity |
(KW) |
23.6*2 |
|
No. of heating zone |
(ZONE) |
6*2 |
|
Max.Output of HDPE |
(Kg/hr) |
350*2 |
|
Oil pump drive power |
(KW) |
11+15=26 |
|
Clamping force |
(KN) |
2000 |
|
Mold stroke (Platen distance) |
(mm) |
400~2800 |
|
Max. Size of Mold(W*H) |
(mm) |
1600*1800 |
|
Capacity of the diehead |
(L) |
65 |
|
Max. Die diameter |
(mm) |
750 |
|
Die heat capacity |
(KW) |
90 |
|
No. of heating zone |
(ZONE) |
24 |
|
Blowing pressure |
(Mpa) |
1.0 |
|
Air volume |
(M3/MIN) |
5 |
|
Cooling water pressure |
(Mpa) |
0.4 |
|
Water consumption |
(L/MIN) |
350 |
|
Size of machine ( L*W*H) |
(m) |
11.5*9*6.9 |
|
Weight of machine |
(TON) |
70-75 |
