High Quality 5 Gallon Water Bottle Blowing Making Machine Price
- shanghai for machine to make bottle plastic
 - T/T Credit Card

You May Like
-


Semi Automatic Plastic Bottle Blowing Machine Price for PET Preform
 -


High Speed Automatic PET Bottle Blow Molding Machine / Blowing Moulding Machine Price
 -


Semi Automatic Pet Blowing Machine,Plastic Bottle Making Machine Prices
 -


Zhangjiagang 3 Gallon Water Bottle , 5gallon PET Bottle Blowing Moulding Machine
 -


3 Gallon Water Bottle , 5gallon PET Bottle Blowing Machine
 -


5 Gallon 20L Bottle Making Machine for Big Plastic Container/semi Auto PET Bottle Blowing Machine

Product Details
| Brand Name | Faygo | Place of Origin | Jiangsu, China | |
| Certification | CE | |||
| Weight | 800kg | Dimension(L*W*H) | L1600*W900*H1600mm | |
| Voltage | 380V/50HZ | Condition | New |
Product Description
 Faygo China plastic bottle making machine with nice price

FG4 is the totally new generation of linear blowing machine. Compared with the convetional blowing machine, It has two main charactristics:
1) High speed: China first Linear blowing machine whose single mold speed can reach 1800 BPH. FG4 has 4 cavities, production speed can reach 7200BPH.
2) Energy saving: The new modularized design make the machine work more efficient
Type  | FG4  | Mark  | ||
Specifications of bottle  | Mould number(piece)  | 4  |
  | |
maxi volume (mL)  | 2000  |
  | ||
maxi height (mm)  | 328  |
  | ||
maxi diameter (mm)  | 105  |
  | ||
Square bottle for max diagonal length (mm)  | 115  |
  | ||
preform Specifications  | Suitable inner bottle neck (mm)  | 20-25  |
  | |
preform max length (mm)  | 150  |
  | ||
Capacity (bottles / hour) at 17 g 500mL  | 7200  |
  | ||
Electricity  | Install power (kw)  | 51  |
  | |
Heating oven total power (kw)  | 46  |
  | ||
Heating oven actual power consumption (kw)  | 26  |
  | ||
Voltage / frequency (V / Hz)  | 380v,50hz  |
  | ||
Allowed voltage fluctuation  | ±10%  |
  | ||
HP Air  | Pressure(bar)  | 30  |
  | |
Capacity(m³/min)  | 4  |
  | ||
Cooling Water  | Mold water  | pressure(bar)  | 4-6  | Water chiller 6HP  |
Suitable temperature range (℃)  | 6-13  | |||
Flow (L / min)  | 45  | |||
Oven water  | pressure(bar)  | 4-6  |
 Water chiller
 3HP
  | |
Suitable temperature range (℃)  | 6-13  | |||
Flow (L / min)  | 22  | |||
Machine Specification  | host machine dimension (m) length × width × height  | 3.3*1*2.3  |
  | |
Weight (Kg)  | 3200  |
  | ||
  Configuration of pet bottle blowing machine
1. Small performs distance heating system
Heater distance in the heating oven is reduced to 38mm, compared with the conventional heating oven it saves more than 30% electricity consumption.
2.Modularized design conception
Adopting modularized design concept, to make it convenient and cost-saving for the maintenance and changing spare parts.
3.Efficient and soft perform inlet system
By rotary and soft preform inlet system, the speed of preform feeding is ensured meanwhile, the preform neck is well protected.
4.Servo driving and cam linking blowing section:
The unique cam linking system integrates movement of mold-opening, mold-locking and bottom mold-elevating in one movement, equipped with high speed servo driving system which greatly shorten the cycle of blowing and increase the capacity.
1. Exploded bottles ejection unit
During the blowing process, if the bottle bursts, bad bottles can be automatically removed. This prevents the bad bottles from entering the filling machine.
2. High pressure air recovery Unit
After the bottle blowing, high pressure air can be recycled and used again for the pre-blowing and machine physical movement.
3. Oven and preform temperature detection unit
Thermal sensing unit detects temperature in oven and temperature of heated performs. When the temperature does not reach the set blowing temperature, blowing workstation will alarm, not blown.
1. Stand-by engineers team to provide overseas installation and commissioning service.
2 1 year warranty. During warranty, we provide free of charge for repairing cost.
3. Lifetime maintenance. After-sales department can provide life long maintenance service.



We can also supply:
 Faygo China plastic bottle making machine with nice price
