Home > Products > UHMWPE lining solutions > high quality pe board anti wear uhmwpe truck liners,coal liner sheet plastic panel supplier

high quality pe board anti wear uhmwpe truck liners,coal liner sheet plastic panel supplier

FOB Price

USD $1 - $1 / Kilogram

500 Kilograms(Min.Order)

Supply Ability 6000 Ton / Tons per Month
Port Tianjin Qingdao
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	XINXING	Place of Origin	Shandong, China
Model Number	XXHG1, 4.5-9 million	Material	PE
Size	1000*1000	Thickness	40

Product Description

UHMWPE bins, hoppers, chutes liners

UHMWPE truck bed liner

UHMWPE bins, hoppers, chutes liners

high quality pe board anti wear uhmwpe truck liners,coal liner sheet plastic panel supplier

Details of UHMWPE flow promotion liners

Material	virgin UHMWPE (UHMW polyethylene)
Service	drilling holes.any design can be made as request
Color	black/white/yellow/blue/red/orange or as request
Installation	simple bolting to rubber backed stick in type liner, space frame construction even welded FLOWLINE drop in liners for fabricated chutes.
Application	for bulk handling applications to reduce typical flow problems of bulk solids in bins, hoppers, chutes, truck beds and other applications plastic lining Bulk storage flow promotion Bulk storage wear liners Ship holds Hoppers Transfer chutes Rail dump hoppers Dump truck liners
Better than steel liners	Traditional steel surfaces can become rough and corroded, causing materials to stick to the surface, causing blockages and reducing productivity and quality. cheaper one third the cost lower in weight UHMWPE Sheet reduces the load on the overall structure.
Advantage	abrasion resistance, promoting bulk material flow, withstanding abrasion
Key Features and Benefits	Impact strength - it is virtually unbreakable. Light weight - easy to handle without special equipment. Electrical insulation - it is a good insulator. Weatherproof - it doesn't absorb water and is UV resistant. Chemical resistance - resists corrosive chemicals(Sulphuric Acid, Caustic Soda). Abrasion resistance - rated better than Carbon Steel for sliding abrasion applications. Flow promotion - ideal product for bulk materials handling.

Size mm Length	Width	Thickness
1000	1000	5-50
2000	1000	5-50
3050	1220	5-50
3030	1550	5-50
4520	2000	5-50
4730	1230	5-50
5040	1330	5-50
6050	1820	5-50
Any size will be made as request.Any size is availible.

Properties of UHMWPE flow promotion liners

Property	Unit	Value
Density	g/cm3	0.93-0.96
Average molecular weight	g/mol	3million- 10 million
Tensile strength (23°C in air)	MPa	22
Breaking strength	MPa	42
Tensile strain at break	%	600
Charpy impact strength (notched)	mJ/mm2	No break
Ball indentation hardness	N/mm2	42
Shore hardness	--	65-70
Abrasion	%	70-80, steel = 100
Static Friction Coefficient		≤0.16
Kinetic Friction Coefficient		≤0.10
Water Absorption		NIL
Elongation at break at 23°C	%	≥300
Melt Temperature	°C	130-140
Temperature Resistance	°C	-269 to +85

Advantage of UHMWPE plates sheets panels

UHMW Sheets are a tough, wear resistant plastic that combines an incredibly low coefficient of friction with outstanding impact strength. These self-lubricating UHMW Sheets have excellent chemical resistance and a broad temperature range making them the perfect choice for engineers in a variety of industries such as conveyor and bulk material handling.

Detailed Images

High performance UHMWPE coal bunker liner/hopper liner supplier

The Steel Plate was replaced due to its poor flow promotion characteristics, high cost and the difficulty of replacement

UHMWPE truck bed liner

Excellent Flow Promotion Properties

Light Weight
