2030ZWW High Torque RC Airplane Bldc Motor 12v 40000rpm Brushless

                                          BRUSHLESS DC MOTOR

____________________________________________________________________________________

 2030 Interior Rotor Without Sensor

Applications: Medical equipment, industrial equipment, navigation models, electrical
tools and mini household appliances,etc.

Operating Environment:-15~+50℃;15~90%RH

Characteristics
			-1-12.0	-2-12.0
1	Voltage	V	12	12
2	Terminal resistance	Ω	0.36	6.1
3	No-load  speed	rpm	43260	9180
4	No-load current	A	0.57	0.25
5	Load torque	mNm	5.0	2.0
6	Load speed	rpm	39420	8640
7	Load current	A	2.66	0.37
8	Max output power	W	63.86	8.18
9	Max efficiency	%	66.3	67.3
10	Back-EMF constant	mV/rpm	0.28	1.31
11	Torque constant	mNm/A	2.39	16.67
12	KV value	rpm/V	3610	770
13	Rotor inertia	gcm2	1.5	1.5
14	Weight	g	40	40
Options
Lead wires length, shaft length, special coils, gearheads, bearing type, encoder, driver
Characteristics Curve
2030
Outline Drawing

Brushless Series

Adopt imported environmental friendly material, CNC machining and dynamic balance test, with the

features of low power consumption, low noise, durable in use, strong overload capacity,  small  electromagnetic

interference, small size, etc. Offer One-stop solution.

Application: medical instrument, industry equipment, aeromodelling plane, electric tool, beauty instrument,

smart home, car product, Office automation equipment.

 About us

• More than 50 sets automatic manufacturing equipment and detecting instruments.
• R&D engineer group with practised experience, and long-term customization
• Professional technical experience and reliable after-sale service
• Good cost control and high cost performance
• ISO9001 quality management system certification
• Up to 50,000 motors daily output

 Customization service as below are available
