Home > Products > Construction Material > Cladding Wall ACP/Acm Aluminum Composite Panel
Cladding Wall ACP/Acm Aluminum Composite Panel
- QINGDAO
- T/T Credit Card
You May Like
Product Details
| Brand Name | Rocky | Place of Origin | Shandong, China | |
| Model Number | rocky-3300 | Function | Anti-Static, Antibacterial, Fireproof, Mould-Proof | |
| Surface Treatment | Anodized, Brushed, Foil Decoration, PE Coated, Printing, PVDF Coated |
Product Description
Cladding Wall ACP/Acm Aluminum Composite Panel
PRODUCTS FEATURES:
1, Light weight, high rigidity and strength
2, Good anti-weathering and anti-corrosiveness properties
3, Good processing quality, able to be processed into various complicated shapes such as plane, arc and spherical surface.
4, Wide selection of colors, good decoration effect
5, Easy to be cleaned and maintained
6, Easy and quick in installation solid panel can be divided into common flat sheet and irregular sheet in terms of shape.
Rocky Fireproof Aluminium Composite Panel
| Coating thickness | ECCA-T1[1995]Comply with customer standard | Kynar 500, 70%+ FC resin 28um + | ||
| Gloss Deviation | ECCA-T2[1995]30 (60 °) +/- 5 E | Gloss | 10% | |
| Colours Deviation | ECCA-T3[1995]ΔΕ≤0.8(CIE - L a b - system) | ΔE | 0.4-0.5 | |
| Pencil hardness | ECCA-T4[1995] ≥H | 2H | ||
| Impact resistance test | ECCA-T5[1995] 1 kg of weight falls from specified heigh | no detainting no cracking | ||
| T-Bending | ECCA-T7[1996] 0T Without severe cracks | 1T | ||
| Coating adhesive | not lower than class 1 | not lower than class 0 | ||
| MEK-test | ECCA-T11[1999] | Over 200 | ||
| Acid Resistance | 70% HNO3 30mins | ΔE< 5% | ||
| Boiling test | Bended sheets 1.0T after 5 minutes in boiling water | without cracks | ||
| Tensile Strenght | 155-180(Mpa) | ≥155 | ||
| Yield strength | ≥130Mpa) | ≥130 | ||
| Elongation | ≥3% | ≥3% | ||
| This test resulte is randomly tested by internal QC department and result in average datebase. | ||||
Aluminium Composite Panel
Specification:
| Standard size | 1220 * 2440 * 4mm |
| Thickness: Range | 3mm, 4mm, 5mm, 6mm, 7mm, 8mm, 9mm 10mm etc |
Length Range | 1220mm, 2440mm, 3200mm, 4000mm, 5000mm, 5500mm, 8000mm |
| Width available | 1250mm, 1270mm, 1500mm, 1575mm. 1600mm, 1700mm, 1800mm |
| Aluminum skin thickness | 0.30 ~ 0.50mm |
| Colors | As GLOBOND color chart show or special color which confirmed by mutual. |
| Coating | America PPG, Kynar 500. PVDF resin painting or FEVE coating. |
| Packing | Protective film and Wooden Pallet |
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q:Do you make customized products based on our design drawings?
A:Yes, we are a professional factory with an experienced engineering team to make custom products as customers request
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q:What is the difference between anodized and mill finished?
A: Mill is the raw state of aluminum as extruded - no surface treatment. Anodized (also known as Satin Clear or Clear Anodized) is an electrolytic process. This process increases corrosion resistance and weather resistance.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q :What are the advantages of using the 6000 series of alloys in aluminum extrusions?
A: The 6000 series, which incorporates magnesium and silicon, provide good extrudability, strength, corrosion resistance, formability and machinability
Q: What is your terms of payment ?
A: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Q: What is Quality Control system?5 steps:
A, After order confirmed, we have a meeting with the main peoples who work for workshop before production,investigate all the workmanship and some technical problems, ensure all of them have related ways to settle and control.
B, Inspect all the materials when arrived, ensure they will be catched up customers's requirements.
C, Inspect the semi-finished goods.
D, Inspect the finished products.
E, Final inspection when pack up all the goods.if there is not any problems for this step,our QC will issue the inspection report and release this products
