HAS VIDEO Plastic Granules Raw Material Making Machine For Ldpe Hdpe Film Pelletizing
- Ningbo China
- T/T Credit Card
You May Like
-
Water Cooling PE PP Waste Bag And Film Granulating Plastic Pellet Making Machine
-
HAS VIDEO High Speed Full Automatic Artistic Bendy Straw Forming Machine
-
HAS Video Flexo Plate Making Machine RZ Series Rubber Flexographic Printer Letterpress Label Printer Automatic Multicolor CN;ZHE
-
Baby , Adult Dry-nurse Medical Automatic Cotton Swab Packing Machine Into Bag With Drying
-
Automatic Paper Plastic Film PVC PET BOPP Slitting and Rewinding Machine With Flat and Disc Knife and Full Automatic Tension
-
HAS VIDEO Chewing Gum , Milk Tablet Alu Pvc Blister Packing Into Cartoning Machine
Product Details
| Brand Name | XIAOHAI | Place of Origin | Zhejiang, China | |
| Model Number | SJ-90 | Certification | ISO9001 | |
| After-sales Service Provided | Engineers available to service machinery overseas | Weight | 3000KG | |
| Dimension(L*W*H) | Model | Voltage | 380v/220v | |
| Application | Granules | Condition | New | |
| Automatic Grade | Automatic | Plastic Processed | PE | |
| Screw Design | Double-screw |
wooden case Double screws Plastic recycling machine
Product Description
PE PP Waste Bag And Film Water Cooling Single Screws Plastic Recycling Machine To Make Plastic Pellets
ONE SCREW MACHINE | |||||
Model | SJ-90 | SJ-100 | SJ-110 | SJ-120 | SJ-135 |
Screw Diameter | 90mm | 100mm | 110mm | 120mm | 135mm |
Screw Ratio | 22:1(L:D) | 22:1(L:D) | 22:1(L:D) | 22:1(L:D) | 22:1(L:D) |
Screw Speed | 10-110rpm | 10-110rpm | 10-110rpm | 10-110rpm | 10-110rpm |
Motor Power | 18.5-22kw | 22kw | 30kw | 37kw | 55kw |
Main Output | 60-80kg/h | 70-90kg/h | 90-110kg/h | 100-130kg/h | 160-180kg/h |
Weight | 2t | 2.1t | 2.2t | 2.5t | 3.5t |
Dimensions | 4800*1250*1100 | 4900*1300*1200 | 5000*1350*1300 | 5200*1400*1350 | 5500*1450*1500 |
TWO SCREW MACHINE | |||||||
Model | SJ-100/90 | SJ-120/95 | SJ-120/100 | SJ-120/110 | SJ-135/120 | SJ-150/125 | SJ-160/130 |
Screw Diameter | 100mm, 90mm | 120mm, 95mm | 120mm, 100mm | 120mm, 110mm | 135MM, 120MM | 150MM, 125MM | 160MM, 130MM |
Screw Ratio | 12:1-8:1(L: D) | 12:1-8:1(L: D) | 15:1-8:1(L: D) | 18:1-8:1(L:D) | 15:1-8:1(L: D) | 22:1-10:1(L: D) | 20:1-10:1(L: D) |
Screw Speed | 10-110rpm | 10-110rpm | 10-110rpm | 10-110rpm | 10-110rpm | 10-110rpm | 10-110rpm |
Motor Power | 15kw; 7.5KW | 18.5kw; 7.5KW | 22kw; 11kw | 37KW; 15KW | 45kw, 15kw | 55kw, 18.5kw | 75kw, 15kw |
Main Output | 60-80kg/h | 80-100kg/h | 120kg/h | 130-150kg/h | 150-170kg/h | 200-220kg/h | 250-280kg/h |
Weight | 1.8t | 2.0t | 2.4t | 3t | 3.5t | 3.8t | 4.5t |
Dimensions | 3000*1000*1500 | 3400*1200*1550 | 3700*1200*1550 | 3600*1200*1550 | 4100*1300*1600 | 4500*1300*1650 | 5500*1300*1700 |
Company Profile
We are a Big Group specializing in making all kinds of printing and plastic machines, such as plastic bag whole line machines (film blowing machines, flexo and gravure printing machines, lamination machines, all kinds of bag making machines), disposable glove making machines, plastic cup and paper cup making whole line machines, drink straw making whole line machines, label whole line making machines, and paper cutting whole line machines.
