Home > Products > Lab Test Apparatus > 1000/2000KN Digital Display Manual Screw Pressure Testing Machine ( Four-post Type)
1000/2000KN Digital Display Manual Screw Pressure Testing Machine ( Four-post Type)
- tianjin
- T/T Credit Card
You May Like
-
DYE-3000KN/300Ton Electric Screw Digital Cement Concrete Pressure Testing Machine (Column Type)
-
2000KN High Strength Electro Hydraulic Digital Cement Pressure Testing Machine
-
ISO New Standard Cement Flexural Jig
-
3000KN/300T Digital Display Manual Feed Screw Compression Testing Machine (Four-post Type)
-
40X40X160mm Flexure Jig For Cement Testing Machine
-
DYE-300KN/30T Digital Cement Flexural Crush Testing Machine
Product Details
| Brand Name | OBRK | Place of Origin | Hebei, China | |
| Model Number | DYE-1000/2000 | |||
| Usage | Cement Testing Machine |
Product Description
1000/2000KN Digital Display Manual Screw Pressure Testing Machine ( Four-post Type)
DYE-1000/2000KN Digital Display Manual Screw Pressure Testing Machine ( Four-post Type)
main purpose:
Mainly used for the test of concrete, cement, brick, refractory materials and other building materials compressive strength test, The product conforms to the standard GB/T50081-2002 Ordinary concrete mechanics performance test method standard, Manually send oil control, digital display, Data storage, easy to operate.
Technical parameters:
DYE-1000/2000 Digital pressure testing machine
The maximum experimental pressure: 1000/2000KN
accuracy class: 1
Test force error value: ± 1%
Test force measurement range:1%-90%
The host structure: Four-post type
The distance between the pillars :240mm/260mm
The size between upper and lower platen:320mm
Platen size:upper dia.100mm,lower 220x220 mm;
upper dia.100mm,lower 220x250 mm
Piston stroke:50mm
Weight:600Kg/850Kg
Power:1000W
Overall dimensions:950 × 3800 × 1200mm; 1030 × 420 × 1600mm
Packing size:1100 × 500 × 1420mm;1200 × 600 ×1700mm
1. Installation and training:
a. If buyers visit our factory and check the machine, we will teach you how to installand use the machine, and also train your workers/technician face to face.
b.Without visiting, we will send you user manual and video to teach you to install and operate.
c.If buyer needs our technician to go to your local factory, please arrange board and lodging and other necessary things.
2. After Service:
a.One year guarantee for whole machine.
b.24 hours technical support by email or calling
c.If there is any problem found of the machine, we will repair it for free in one year.
Frequently Asked Question:
1.Are you trade company or factory?
We are trade company but we also have own factories. Building trade company is just for exporting various types of concrete mould and others products.
2. Why your price is higher than others?
As we persist on that each factory should put quality at the first place. We spend time and money on developing how to make machines much more automatic, accurate and high quality. We can make sure that our machine could use more than ten years without any problem. We can provide one years free quality assurance.
3. How to visit your company?
A) Fly to Beijing airport: By high speed train From Beijing Nan to Cangzhou Xi (1 hour),then we can pick up you.
B) Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou Xi(4.5 hours), then we can pick you up.
Oubeiruike supply verious type of products,Test Molds, Concrete Mixer,Asphalt Tester,and Soil Road Lab Tester .... We assure high quality to you.
