800W Permanent Magnet Electric Wheelchair Motor DC 24V
- 100000 Piece / Pieces per Month
- Shanghai
- T/T Credit Card
You May Like
Product Details
| Brand Name | JINLE | Place of Origin | Jiangsu, China | |
| Model Number | M208XXN | |||
| Certification | CE | Torque | 2N.m | |
| Usage | Boat, Car, Electric Bicycle, Fan, Home Appliance | Construction | Series Wound | |
| Efficiency | IE 4 | Protect Feature | Drip-proof | |
| Continuous Current(A) | Current | Speed(RPM) | 3200RPM | |
| Commutation | Brush |
Product Description
800W Permanent Magnet Electric Wheelchair Motor DC 24V
Features:
100% copper wire
stable running, high efficiency, low noise
good service after sale
12V, 24V, 48V, 60V etc. on your request
Customized production is available!
Supply for OEM Production!
nearly 20 years' manufacturing experience
Specification:
1) Type: M208XXN
2) Voltage: 24V
3) Power: 0.8KW
4) Speed: 3200PM
5) Rotation: CW
6) O.D. : 80mm
7) Operating mode: S3
8) Insulation Class: F
9) Protection Degree: IP 54
10) Torque: 2N.m
11) Weight: 2.5KG
Unload | Speed | 5091 RPM |
Current | 10.230 A | |
Max_Torque | Torque | 2.670 N.m |
Current | 64.340 A | |
Speed | 3639 RPM | |
Efficiency | 66.35% | |
Output Power | 1017.40 W | |
Max_Efficiency | Efficient | 69.36% |
Speed | 4016 RPM | |
Torque | 1.770 N.m | |
Current | 44.200 A | |
Output Power | 744.30 W | |
Max_Pout | Efficiency | 66.35% |
Speed | 3639 RPM | |
Torque | 2.670 N.m | |
Current | 64.340 A | |
Output Power | 1017.40 W |
