High Quality and Efficient Single Spiral Freezer for Fish Seafood

Description

Self-stacking sprial freezer is a kind of spiral freeze without tranditional rail support, the top belt supports by the bottom belt, its own support structure for compact building dimensions. Self-contained freezing zone, with benchmark hygiene (100% air flow), high efficency and lower consumptions advantages, reliable and less maintenace realized comes from high quality of Aerospace technology; continous producing creates by comprehensive cleaning system-lower consumption of water, energy and chemicals. So it is more suitable for meat balls, fish balls, sausage, Spring rolls, chicken wings, legs, etc.

Model&Specification

Model                                                       LX-800

Output                                                      800kg/h

Feeding temp.                                          15 ℃

Circulating cold air temperature              -35+-2 ℃

Dimension of freezing room                    9.05*7.2*2.85m

The length of wire mesh belt                   235m

The width of wire mesh belt                    650mm

Layers number                                         11

The space between two layers                 145mm

Refrigerate capacity needed                    145Kw

Refrigerating condition                           Tz=-40℃ T_k=35℃

Electric installation Power                       25Kw

Product Pictures

Our equipment can process the following products:

Features

Thoroughly sanitary freezing environment

1 According to HACCP sanitary safety concept, the inner is designed for simple cleaning and maintenance, fully conforming to food sanitary requirements.

2 The internal body and mesh belt are made of stainless steel SUS304.

3 With hydrophilic film, the fins of heat exchanger can be avoided from harmful powder of alumina.

4 All roller wheel, turn hub,and guideway are made of sanitary ultra-high molecular weight polyethylene.

Advantages

1 Arc air deflector, uniform inner temperature and efficient working capacity;

2 Fined type evaporator, exchanging heat efficiently and cooling down quickly keep reliable and stable;

3 Advanced design in guarantee stable running;

4 Strict manufacture installation to ensure accuracy and reliability;

5 Multiple alarm system to eliminate incipient fault.

Detail components of equipment

1. Products conveyor parts, inclued ahead section, conveyor belt. Plenum chamber, air guider, belt drive system.

2. Enclosure, assembly by polyurethane sandwich board and insulated access doors.

3. Cold air circulating part, include evaporator and frame, water defrosting system, fans.

4. Control part include electric control cabinet with switches, display apparatus, indication lamps, frequency converter, etc.

5. Internal maintenance walks way.

6. Protect parts include protect screens.

1. We guarantee that the commodity hereof is made of the best materials and new brand with top workmanship, and in accordance with quality specification stipulated in product Contract and Appendix.

2. Guarantee period shall be within 12 months from the date of acceptance. During this period, if there are quality problems, we will provide solution by verbal or written communication. If the problem is unsolved, our engineers will repair for you on site as soon as possible. The maintenance is free when there are non-operation errors; otherwise it is for the buyer’s account.

Training plan: We will provide training for those who operate and maintain the freeze-drying machines. Trained by supplier of the equipment in the process of installation and debugging, people can operate  and solve the basic mechnical problems independently. In addition, the persons who work in general engineering such as refrigeration, boiler, and transformer substation shall be undertaken by skilled workers.
