Ductile Iron Restraint Dismantling Joint

It is used  for all flanged piping materials line .

Flanges and drillings to ISO7005-2 ( BS EN1092-2:1997,DIN2501)

The dismantling joint enables easy installation and dismantling of isolating valves , non return valves , flow metering equipment , pumps etc.

It compensates for axial displacement of the pipe during installation/dismantling .

 All the materials of the body is ductile iron according to GGG500-7 and the bolts and nuts are hot galvanized coating .The rubber seal is EPDM  For drinking water.

Size : DN80-DN1200

Pressure : PN10 PN16 PN20

Packing : plywood cases ,pallets or according to the requirment of buyers

1.Inspection:Foundry in-house; Third Party inspection available upon request

2.Packing: Wooden pallet ; Cases ; As customer ruqirement .

3.Delivery Date:40 days ; According to the quantity .

4.Payment: 30% by T/T in advance, the balance before Shipping .

QINGDAO VALTECH MANUFACTURING CO., LTD.

We are a joint venture specializing in manufacturing and exporting Ductile Iron pipe fittings,

accessories and their joints for water supply pipeline. Being in the lines for 10 years, we can assure

you that our products are of good quality and reasonable price.
