Customized XLPE Insulated UV Resistant 10mm 16mm 25mm Solar Cable DC Splitter Solar Cable
- Shenzhen
- T/T Credit Card
You May Like
-
IP68 Waterproof Flexible XLPE Double Insulated DC 6mm2 Solar Cable
-
Factory Price XLPE 1000V 1500V DC 2PfG 1169 PV1 F 1x4mm2 UV Resistant Solar Panel Cable
-
High Current IP68 Waterproof Electric Cable Copper Solar Wire 4mm2
-
TUV & CE Approved XLPE DC Solar Cable 4mm2 Single Core Wire
-
10 AWG Single Core Solar Cable for Solar Energy Program
-
Crush Resistance Photovoltaic 2.5 Mm2 Cable Wires for Solar System
Product Details
| Brand Name | Slocable | Place of Origin | Guangdong, China | |
| Model Number | CA110B-PE solar cable | Type | High Voltage | |
| Conductor Material | Copper |
Product Description
Customized XLPE Insulated UV Resistant 10mm 16mm 25mm Solar Cable DC Splitter Solar Cable
Product Description
| Size | Cross Section | Conductor Structure | Outer Diameter |
Max. DC Resistance at 20℃ | Rated Voltage | Rated Current |
| mm² | mm | mm | Ω/km | V DC | A | |
| 1 x 2.5mm² | 2.5mm² | 49 x ∅0.25 | 5.4 | 8.06 | 1000/1500 | 30A |
| 1 x 4.0mm² | 4.0mm² | 56 x ∅0.285 | 6.1 | 4.97 | 1000/1500 | 50A |
| 1 x 6.0mm² | 6.0mm² | 78 x ∅0.30 | 6.4 | 3.52 | 1000/1500 | 70A |
| 1 x 10.0mm² | 10.0mm² | 74 x ∅0.40 | 7.3 | 2.12 | 1000/1500 | 95A |
Technical Data
Conductor: 99.7% copper, tinned | UV resistance |
| Insulation material: XLPE(XLPO) | High voltage and High current |
| Double walls insulation | Temperature range: -40°C ~ +85°C |
| Halogen-free material | Color: Black/Red/Blue |
| Flame test according to: DIN EN 50265-2-1 UL 1571(VW-1) | Smallest permissible bending radius: 5 x D |
Advantages of Product
- Dual wall insulation,Electron beam cross-linked.
- Resistance to UV,water,ozone,fluids,salt,general weathering.
- Halogen free,flame,retardant,low toxicity.
- Flexibility and stripping performance.
- TUV approved.
- High current carrying capacity.
- Resistance to abrasion.
Frequently Asked Question
Q1: What is your company's Main Products ? You are the Manufacturer or the trader ?
Solar Cables, Solar Connectors, PV Fuse Holder,Circuit breakers and other
solar relative products.We're the Manufacturer with more than 11 years experience.
1) All raw material we selected the high quality one.
2) Professional & Skilful workers care every details in handling the producing.
3) Quality Control Department specially responsible for quality checking in each process.
Q4: Do you provide OEM Project Service ?
OEM & ODM order is warmly welcome and we have fully successful experience in OEM projects.
What's more, our R&D team will give you the professional suggestions.
Q5: How Could I get the Sample?
We are honored to offer you samples,Samples is free provided,but need pay the courier freight.
If you have a courier account, you can send your courier to collect samples.
Q6: How long is the Delivery Time?
1) For Sample: 1-3 Days ;
2) For small Orders: 3-10 Days;
3) For mass Orders: 10-18 Days.
