SEAFLO 12V DC 3 inch Diameter Submersible Water Pump With Internal Float Switch
- 1000 Piece / Pieces per Month
- T/T Credit Card
You May Like
-
SEAFLO 12V DC 16LPM Small Diameter Low Voltage Submersible Pump
-
SEAFLO 12V DC 16LPM Small Diameter Pumps Submersible Water Pump
-
SEAFLO 12V DC 16LPM Small Diameter Centrifugal Water Submersible Pump
-
SEAFLO Deep Well High Flow Submersible Automatic Solar Water Pump 2 Inch Diameter
-
SEAFLO 24VDC Solar Pumps Powered Water Pump System for Agriculture System
-
SEAFLO 24VDC 103GPM 0.5Hp Submersible Solar Water Pump
Product Details
Brand Name | SEAFLO | Place of Origin | Fujian, China | |
Model Number | SFSP-G500-02A | Application | Submersible | |
Power | Electric | |||
Usage | Water | |||
Pressure | Low Pressure |
Product Description
Features & Benefits |
1.Flow rate avaiable from 190 GPH to 4700 GPH 3.Be able to connect wtih solar panel 5.Stainless steel shaft 7.Quiet operation | 2.Entirely submersible 4.Compact design 6.Anti-air lock & igniton protection 8.Designed for fluid transfer |
Product Name | SEAFLO 12V DC 3 inch Diameter Submersible Water Pump With Internal Float Switch |
Pump Type | Centrifugal Submersible Inline Pump |
Max Flow Rate | 500 GPH [1893 LPH], more flow rate are available |
Max Head | 32' [10 m], more head are available |
Voltage | 12 VDC, and 24V, 115V, 230V are available |
Max Amp | 4.5 A |
Fuse | 7.5 A |
Outlet Port | 3/4" [20 mm] Barb |
Inlet Port | 3/4" [20 mm] Barb & Strainer Base |
Duty Cycle | Continuous |
Protection | Anti-airlock & Igniton Protection |
Max Fluid Temp | 80°C water & 40°C diesel |
Lead | 16.4' [5 m] 18 AWG lead with clip |
SEAFLO inline submersible and inline pump is easy to install and carry. Also, the pump is able to pump seawater and diesel. With long life and quiet perform motor, allows it to work in an quiet environment. The food grade material allows it to work with wide range of application.
Product Show |
Dimensions |
Performance |
Motor Heat Rise |
Lacking
Product Details |
Lacking
STANDARD PUMP CONFIGURATIONS
Model | Voltage | Open Flow GPH [LPH] | Head Ft [m] | Outlet Port | Lead & Clip | Pumping Liquid |
SFSP1-G200-03B | 12 V | 200 [757] | 32’ [10 m] | 1/2" [11 mm] | 3' [1 m], without clip | Water only |
SFSP1-G280-02A | 12 V | 280 [1060] | 32’ [10 m] | 1/2" [11 mm] | 16' [5m], with clip | Water & Diesel |
SFSP1-G280-02B | 12 V | 280 [1060] | 32’ [10 m] | 1/2" [11 mm] | 3' [1 m], without clip | Water & Diesel |
SFSP1-G500-02A | 12 V | 500 [1892] | 32’ [10 m] | 3/4" [20 mm] | 16' [5m], with clip | Water & Diesel |
SFSP1-G500-02B | 12 V | 500 [1892] | 32’ [10 m] | 3/4" [20 mm] | 3' [1 m], without clip | Water & Diesel |
OEM/ODM service: Open flow is avaiable from 190 GPH [720 LPH] to 4700 GPH [17789 LPH]; Head is avaiable from 9 ft [3 m] to 32 ft [10 m]. Material can be adjusted according to your requirement.
Package Infomation
Unit Pump Weight | 1.2 lbs [0.54 kg] | |
Selling Unit Size (L x W x H) | 11.40" x 8.30" x 0.28" [29.0 x 21.0 x 0.7 cm] | |
Selling Unit Weight | 1.4 lbs [0.63 kg] | |
Master Carton Qty | 15 pcs / carton | |
Master Carton Size (L x W x H) | 25.9"x 15.4" x 13.58"(65.8 x 39.2 x 32.0 cm] | |
Master Carton Weight | 26.2 lbs [11.8 kg] |
Q: What is your MOQ?
A: 100 pieces in general, but no MOQ requirement for sample testing.
Q: Do you accept OEM/ODM service?
A: Yes. We are also the OEM/ODM supplier for many famous companies, such as Volvo, Bunnings etc.
Q: How can I pay for my order?
A: Please send order details to us. We will issue an order on Alibaba Trade Assurance, and send you the payment link.
Q: What is your terms of payment?
A: Payment≤3000USD, 100% in advance. Payment≥3000USD, 30% T/T in advance, balance against the copy of B/L. If you have another questions, pls feel free to contact us.
Q: What is the delivery time?
A: It depends on the order quantity. It usually takes 15-25 days upon receipt of your 30% deposit by T/T. Sample can be delivered within 7 days.
Q: Can I buy different products in one container?
A: Yes, you can mix different models of pumps in one container.
Q: What is your warranty?
A: 1 year, and within 24 hours reply will be provided to solve customers' problems.
Q: What is your port of loading?
A: Xiamen port.
Q: Do you have oversea agents?
A: We dont have oversea agents for Agriculture and Industrial. But for SEAFLO pumps applied in Marine & RV, we have agents in USA, UK, Denmark, Spain, Australia, Turkey, Yemen, Lebanon etc.
Q: Can I get more info?
A: Please visit or www.seafloin.en.china.cn for more information.
