Home > Products > Ordinary diagnosis instrument > MY-G079 New syringe infusion pump/portable infusion pumps/volumetric infusion pump for sale
MY-G079 New syringe infusion pump/portable infusion pumps/volumetric infusion pump for sale
- T/T Credit Card
You May Like
-
MY-G081 Medical device cheap veterinary syringe pump with good quality
-
MY-G082 Medical Maya manufacturer cheap price of syringe pump for sale
-
MY-G083 Hot sale Syringe Pump (Double Channel) (without drug library)
-
MY-G054A Medical Professional ENT video laryngoscope endoscope/optical flexible laryngoscope
-
MY-G062A Portable Vein detector Vein finder
-
MY-G044B Medical Equipment Hospital digital otoscope
Product Details
| Brand Name | MAYA | Place of Origin | China | |
| Model Number | MY-G079 |
Product Description
MY-G079 2018 New syringe infusion pump/portable infusion pumps/volumetric infusion pump for sale
MY-G079 syring pump
Function and Features
Three kinds of modes: Rate Mode, Time Mode, Body Weight Mode.
Double CPU, making the process of injection safer and more reliable.
Accurate and sensitive pressure sensor detecting occlusion pressure accurately.
Injection time, dose, solution can be checked during the process of injection.
Precision step motor. There is no pulsating wave even during low-rate injection.
KVO rate can be selectable according to concrete requirements from 0.1ml/h to 5ml/h.
Excellent injection operation. The accuracy will be ensured even at small-volume injection.
Unique injection supervision system ensures the safe injection and reduces the nurse’s workload.
Accept all standard syringes of 5ml, 10ml, 20ml, 30ml and 50ml. It will self-diagnose and display the syringe size and set parameter automatically in the form of menu.
Alarm is given when there is malfunction or operation error, and the machine stops running automatically.
Save the preset volume automatically when there is unpredictable switch off, ensuring the accuracy of injection volume.
Technical parameters of MY-G079 Syringe pump
Applicable syringes | All brands of standard syringes: 5ml,10ml,20ml,30ml,50ml |
| Weight | <3.0kgs | |
Accuracy | ±2% | Dimension | 310*125*115mm | ||
Injection increment | 0.1ml | Power supply | AC100~240V, 50/60Hz | ||
Occlusion value | 40kPa~160kPa | Fuse | T2AL250V~ | ||
Injection rate | 5ml: 0.1 ml/h -100ml/h 30ml: 0.1 ml/h -600ml/h 10ml: 0.1 ml/h -200ml/h 50ml: 0.1 ml/h -1500ml/h 20ml: 0.1 ml/h -400ml/h | Maximum power consumption | 25W, can run for 4h after being recharged | ||
Battery | Rechargeable lithium polymer battery, 7.4V, 1600mAh | ||||
Accumulated injection volume | 0.1ml~9999.9ml |
Battery recharge | When the pump is connected to the AC power supply, turn on the power and the battery will automatically recharge (about 8~14 hours to recharge fully.) | ||
Modes of operation | Selectable: Rate mode, Time mode, Body Weight mode | ||||
Time mode | Volume limit: 0.1~999.9ml Time:1~2000 minutes | ||||
Electrical safety
| Comply with the stipulation of IEC60601-1: 1996 | ||||
Body weight mode | Drug limit:0.1~999.9mg, Solution limit:0.1~999.9ml, Weight: 01~300.0kg, Dose: 0.1~9999.9 mg/kg/h, ug/kg/min | ||||
Electromagnetic compatibility | Comply with the stipulation of IEC60601-1-2: 2006 | ||||
Displayed information | Rate, volume limit, accumulated injection volume, syringe size, pressure value, battery capacity, unit of medical dosage, bed No., AC power indicator, battery charge indicator, drug name, bolus rate | Shell material | ABS plastic | ||
Classification | II Class-BF | ||||
Alarm function | OVER, NEAR, Occlusion, Low battery, Syringe disengaged, No AC power supply, serious low battery | Operating conditions | Environment temperature 5°C ~40°C, air pressure 80kPa ~106kPa, relative humidity ≤80% | ||
Storage conditions | Environment temperature -40°C~55°C, air pressure 50kPa ~106kPa, relative humidity ≤95% | ||||
KVO rate | 0.1ml/h-5.0ml/h (selectable) | Applied standards | IEC60601-1: 2005 IEC60601-2-24: 1998 IEC60601-1-2: 2006 ISO780-1997 ISO15223: 2000 ISO7886-1: 1993 ISO / IEC: Guide No. 37(Consumer Goods Usage Instructions) | ||
Bolus rate | 5ml: 100ml/h 10ml: 200ml/h 20ml: 400ml/h 30ml: 400ml/h-600ml/h 50ml: 400ml/h-1500ml/h |
Product picture:
1. For all your inquires about us or our products, we will reply you in detail within 24 hours.
2. We own professional team with professional attitude to recommend products and services, introducing the products for you.
3. Our products have various type and function, We will recommend to you that according to your requirements ; The products have one year free warranty, after which they can still be provided after-sales service.
4. We offer OEM services, And we can print your own logo on the products.
5. We have well-experienced engineers, who can help you better use our products.
Your satisfaction is our duty! It will be our great honor to serve you. We do hope we can offer you more help in medical field and build the long term business relationship with you.
Q: How to buy your products ?
A: We have some products in stock , you can take away the products after you arrange the payment ; If we don’t have the products in stock you want, we will start production once getting the payment.
Q: What’s the warranty for the products ?
A: The free warranty is one year from the date of commissioning qualified.
Q: Can we visit your factory ?
A: Of course, welcome to visit our factory if you come to China.
Q: How long is the validity of quotation ?
A: Generally, our price is valid within one month from the date of quotation. The price will be adjusted appropriately as the price fluctuation of raw material in the market.
Q: What’s the production date after we confirm the order ?
A: This depends on the quantity. Normally, for the mass production, we need about one week to finish the production.
Please contact us for more detail information.
Delivery detail:
1.We ship the products by air or sea for you.
2.Our products with standard export packing.
3.No matter what delivery way, all depending on your actual requirements.
