Home > Products > Garage equipment > High Precision Vertical Cylinder Boring Machine for Engine Block Surface (T8018C)
High Precision Vertical Cylinder Boring Machine for Engine Block Surface (T8018C)
- 1000 Piece / Pieces per Month
- T/T
You May Like
Product Description
Specifications
650 boring depth! Vertical Boring Machine T8018C for wide use
Vertical fine Boring Machine
Boring machine
Features
The machine is mainly used for boring the cylinder hole of internal combustion engine and the inner hole of cylinder sleeve of cars or tractors, and also for other machine element hole.T8018C is used for processing special large motor cylinders. The machines are with the advantages of cramped structure, reliable performance, wide uses and high processing accuracy, etc
| Main specification | Unit | T8018C |
| Boring diameter | mm | φ42-180(with optionals) |
| Max.boring depth | mm | 600(with optionals) |
| Max.spindle travel | mm | 800 |
| Distance from spindle axle to body | mm | 355 |
| Spindle speed | r/min | 175,230,300,350,460,000 |
| Spindle feed | mm/r | 0.05,0.10,0.20 |
| Fast moving speed of spindle | mm/min | 2800 |
| Table size L*W | mm | 1680*450 |
| Table travel | mm | crosswise 1500 |
| Manual table movement per circle of handwheel | mm | 5 |
| main motor | kw | 3.3/4 |
| Motor for spindle fast motion | kw | 0.75 |
| Table feeding motor | kw | 0.75 |
| Overall size L*W*H | mm | 2680*1500*2325 |
| Packing size L*W*H | mm | 1880*1550*2550 |
| Net weight/gross weight | kg | 3000/3200 |
