Home > Products > Angular Contact Ball Bearing > High Precision Angular Contact Ball Bearings 7206 30x62x16 for Sale
High Precision Angular Contact Ball Bearings 7206 30x62x16 for Sale
US$ 7 - 9
/ Piece
10 Pieces(Min. Order)
- Shandong or other ports
- T/T Credit Card
You May Like
-
High Quality QJ Series QJ 210 MA QJ210 Four Point Angular Contact Ball Bearing Industrial Bearings Size 50x90x20
-
180BN19 High Quality and Useful Excavator Bearing Famous Brand Bearing 250*180*33
-
5307 5308 5309 5310 35*80*34.9mm Double Row Angular Contact Ball Bearing
-
7315 7313 7314 7315 7316 7217 High Speed Angular Contact Ball Bearing for Drilling Platform 7315 Bearing
-
High Quality Single Row 7217 BECBM BECBY Precision Angular Contact Ball Bearing 7217B Size 85x150x28
-
QJ Series Bearing QJ212 Four Point Angular Contact Ball Bearing Size 60x110x22mm Precision Bearing
Product Details
| Place of Origin | Shandong, China | Model Number | 7206 | |
| Number of Row | Single Row | Seals Type | Open, 2RS, 2Z | |
| Precision Rating | P0 P6 P5 P4 |
Product Description
High precision angular contact ball bearings 7206 30x62x16 for sale
Product Description
Angular contact ball bearings have inner and outer ring raceways that are displaced relative to each other in the direction of the bearing axis. This means that these bearings are designed to accommodate combined loads, i.e. simultaneously acting radial and axial loads.
Angular contact ball bearings are available as:
single row angular contact ball bearings
double row angular contact ball bearings
four-point contact ball bearings
Super-precision angular contact ball bearings
Double row cam rollers
Hub bearing units
Specifications: | |
Bore diameter | 30 mm |
Outside diameter | 62 mm |
Outer ring width | 16 mm |
Overall width | 16 mm |
Maximum rpm | 13000 RPM |
Radial dynamic load capacity | 22.5 kN |
Radial static load capacity | 14.3 kN |
Contact angle | 40 ° |
Row type & fill slot | Single-Row Non-Fill Slot |
Closure type | Open |
Fillet radius | 1 mm |
Cage material | Nylon |
| Ball Bearing Model No. | d(mm) | D(mm) | B(mm) | |
| 7000CTYNSULP4 | 7000A5TYNSULP4 | 10 | 26 | 8 |
| 7001CTYNSULP4 | 7001A5TYNSULP4 | 12 | 26 | 8 |
| 7002CTYNSULP4 | 7002A5TYNSULP4 | 15 | 32 | 9 |
| 7003CTYNSULP4 | 7003A5TYNSULP4 | 17 | 35 | 10 |
| 7004CTYNSULP4 | 7004A5TYNSULP4 | 20 | 42 | 12 |
| 7005CTYNSULP4 | 7005A5TYNSULP4 | 25 | 47 | 12 |
| 7006CTYNSULP4 | 7006A5TYNSULP4 | 30 | 55 | 13 |
| 7007CTYNSULP4 | 7007A5TYNSULP4 | 35 | 62 | 14 |
| 7008CTYNSULP4 | 7008A5TYNSULP4 | 40 | 68 | 15 |
| 7009CTYNSULP4 | 7009A5TYNSULP4 | 45 | 75 | 16 |
| 7010CTYNSULP4 | 7010A5TYNSULP4 | 50 | 80 | 16 |
| 7011CTYNSULP4 | 7011A5TYNSULP4 | 55 | 90 | 18 |
| 7012CTYNSULP4 | 7012A5TYNSULP4 | 60 | 95 | 18 |
| 7013CTYNSULP4 | 7013A5TYNSULP4 | 65 | 100 | 18 |
| 7014CTYNSULP4 | 7014A5TYNSULP4 | 70 | 110 | 20 |
