Stainless Bearing Nsk 623zz Deep Groove Ball Bearing Miniature Size 3x10x4mm Double Shielded
- Guangdong Qingdao
- T/T Credit Card
You May Like
-
Ball Bearing List 6052 2RS ZZ Deep Groove Ball Bearing 260X400X65mm With Factory Price List
-
Ball Bearing List 6088 2RS ZZ Deep Groove Ball Bearing 440X650X94mm With Factory Price List
-
Car & Motorbike Alternator Parts B17-116 B17-116D-2RS Nsk Bearings Sealed Deep Groove Ball Bearing Size 17x52x18
-
Ball Bearing List 6240 2RS ZZ Deep Groove Ball Bearing 200X360X58mm With Factory Price List
-
Ball Bearing List 6320 2RS ZZ Deep Groove Ball Bearing 100X215X47mm With Factory Price List
-
Online Sale 6232-M-C3 6032 6232 6332 Open Type Extra Large Deep Groove Ball Bearing Heavy Duty Bearings
Product Details
| Place of Origin | Shandong, China | Model Number | 623zz | |
| Number of Row | Single Row | Seals Type | Open, 2RS, 2Z | |
| Precision Rating | P0 P6 P5 P4 |
Product Description
stainless bearing nsk 623zz deep groove ball bearing miniature size 3x10x4mm double shielded
NSK deep groove ball bearings are available in a variety of sizes and are the most popular of the rolling bearings. This type of bearing supports radial load and a small degree of axial load in both directions simultaneously. Deep groove ball bearings are popular due to their versatility, affordability, and capability to run at high speeds. Most bearings in the 6000 series up to 60mm bore can be made available in stainless steel (AISI 440C material) upon request. Contact a BHR sales engineer for details.
Specifications: 623zz nsk deep groove ball bearing 623-2Z single row | |
Clearance | C3 C4 C0 |
Ball bearing type | deep groove ball bearing |
Number of row | single row |
| Seal type | open bearing, sealed bearing 2RS 2Z |
| Precision rate | grade p4 p5 p6 p0 abec5 |
Brand | japan brand bearings nsk |
Dimensions: | |
Bore size d | 3.000 mm |
Outside Diameter D | 10.000 mm |
Outside Ring Width B | 4.000 mm |
Weight | 0.0016kgs |
Basic Load Ratings: | |
Cr - Dynamic Load Rating | 0.63 kN |
C0r - Static Load Rating | 0.22 kN |
Factors: | |
Grease Reference Speed | 66000 rpm |
Oil Reference Speed | 700 rpm |
bearing NSK deep groove ball bearing catalogue 6200 series
| New No. | Old NO. | ID | OD | B | Mass |
| 6200 nsk bearing | 200 | 10 | 30 | 9 | 0.032 |
| 6201 nsk bearing | 201 | 12 | 32 | 10 | 0.037 |
| 6202 nsk bearing | 202 | 15 | 35 | 11 | 0.045 |
| 6203 nsk bearing | 203 | 17 | 40 | 12 | 0.065 |
| 6204 nsk bearing | 204 | 20 | 47 | 14 | 0.106 |
| 6205 nsk bearing | 205 | 25 | 52 | 15 | 0.128 |
| 6206 nsk bearing | 206 | 30 | 62 | 16 | 0.199 |
| 6207 nsk bearing | 207 | 35 | 72 | 17 | 0.288 |
| 6208 nsk bearing | 208 | 40 | 80 | 18 | 0.368 |
| 6209 nsk bearing | 209 | 45 | 85 | 19 | 0.416 |
| 6210 nsk bearing | 210 | 50 | 90 | 20 | 0.463 |
| 6211 nsk bearing | 211 | 55 | 100 | 21 | 0.603 |
| 6212 nsk bearing | 212 | 60 | 110 | 22 | 0.789 |
| 6213 nsk bearing | 213 | 60 | 120 | 23 | 0.99 |
| 6214 nsk bearing | 214 | 70 | 125 | 24 | 1.084 |
| 6215 nsk bearing | 215 | 75 | 130 | 25 | 1.171 |
| 6216 nsk bearing | 216 | 80 | 140 | 26 | 1.448 |
| 6217 nsk bearing | 217 | 85 | 150 | 28 | 1.803 |
| 6218 nsk bearing | 218 | 90 | 160 | 30 | 2.17 |
| 6219 nsk bearing | 219 | 95 | 170 | 32 | 2.62 |
| 6220 nsk bearing | 220 | 100 | 180 | 34 | 3.19 |
![]() | ![]() | |
![]() | ![]() |
