4K HEVC/H.264 Encoder 9000 Broadcast Level Device 32 channels IPTV HD H.265 Transcoding
- 1000 Piece / Pieces per Month
- Beijing
- T/T Other
- 7 days
You May Like
Product Description
YW9000 HP @ L5.1
H.265 HD/SD real time transcoder, up to MP @ L6..2
Support H.265 10bit 4K encoder, support HDR(HLG)
Backup support for single device: IP input and IP output
Analog Input: up to 12 channels
SPTS and MPTS supported for both IP and ASI input
0 ~ 48 hours delay, adjustable
IP Output Protocol: TS over UDP/RTP/HTTP/RTSP; FLV over HTTP/RTMP; HTTP Live Streaming; 3GP over RTP; MMS; File over Samba/NFS ;3GPP
Video Input Format: MPEG1/MPEG2/MPEG4/H.264/H.265/WMV/DIVX/M-JPEG/RMVB
Audio Input Format: WAV/MPGA/AAC/WMA/MP3/AMR/AC3
IP Input Protocol: UDP/RTP/RTSP/MMS/HTTP; File over Samba/NFS
Multi H.265 Channels: HD: 32; SD: 64
Device control: Web or SNMP
Completely Support: from one input stream to multi-profile, multi-format, multi-protocol, and multi-interface output streams
ASI output: both internal services and external services (from IP to ASI directly) are supported
Support FLV live video
Support 3GP
Support IPhone and IPad Series video live
Support 3 dynamic Logo overlay and 2 subtitle overlay
System Backup Support: 1+1 or N+M
Various Applications: DVB/IPTV/WebTV/Mobile TV/Offline Transcoding/…
SNMP Protocol software supports real time status monitor, alarm message, log storage
Specification:
4096/1920/1440/1280/1024/800/720/704/640/544/480/416/352/320/240/220/192/176/144/160/128/96/8 | |
Video Vertical Resolution | 2160/1080/768/720/600/576/480/288/240/192/180/176/144/140/128/120/96/90/80/64 |
Video Encoding Format | H.264.H.265/AVC Main Profile Level1-3 |
H.264.H.265/AVC High Profile Level4 | |
MPEG-2 Main Profile, Main Level; MPEG-2 Main Profile, High Level
| |
WMV:WMV1/WMV2/WMV3(Microsoft WMV9) | |
Audio Encoding Format | MPEG1 Layer II /AAC /AC3 /WMA/MP3/AMR |
Audio Input Interface | 2 Analog balanced channels |
SDI embedded audio, Up to 3 stereo channels | |
Input Interface | S Over IP |
4xSDI(optional) | |
4x3G-SDI (optional) | |
1X12G-SDI (optional) | |
4XHDMI (support HDCP, optional) | |
6xAV (optional) | |
AES-EBU (optional) | |
Output Interface | Two DVB-ASI output |
Two 100/1000M TS Over IP output | |
Physical and Power | |
Weight:9Kg | |
Power:100-240 VAC Auto-ranging | |
Power Consumption: Max 300W | |
Operating Temp: 0℃-+50℃ | |
Humidity: 5-95% |
YW9000 4K H.265 Encoder/Transcoder Config List
Config List | YW9000- IP | YW9000- AV | YW9000-SDI | YW9000 HDSDI | YW9000 4K | YW9000 HDMI | |
Video Format | HD | √ | X | X | √ | √ | √ |
SD | √ | √ | √ | √ | √ | √ | |
Input Interface | IP | √ | √ | √ | √ | √ | √ |
AV | X | √ | X | X | X | X | |
HD-SDI | X | X | X | √ | X | X | |
3G-SDI | X | X | X | X | √ | X | |
12G-SDI | X | X | X | X | √ | X | |
HDMI | X | X | X | X | X | √ | |
Output Interface | IP | √ | √ | √ | √ | √ | √ |
Video Encoding Format | MPEG-2 | Main Profile, Main Level | |||||
H.264, H.265 | Profile: Baseline/Main/High Level: 1.0 ~ 4.0 Bitrate: 8k ~ 20M | ||||||
Audio Encoding Format | MPEG1-Layer2 | √ | |||||
AAC | √ | ||||||
AC3 | √ | ||||||
