Ship/Vessel Sound and Visual Alarm Navigation Light Control Panel

Description:

  Navigation light controller of HXD-1 series consists of one display model and two connection units. Commonly, the control panel is embedded installed on the brigdge.The navigation light controller is used to monitor and control the navigation light during sailling. HXD-1 can be delect the status of 28 navigation lights, once some wire or signal cable broken, the power operation lights will blink, the alarm will sound at the same time, then you can press the silent-button to stop.

  The control board has touchable dimmer button, u can change the brightness of the LED.HXD-1 control board has two auto-switched power:AC220V and DC24V or both AC220V available. When all the way in which a power failure, power light flashes and alarm sounds.

  HXD-1 navigation light controller compliant fully with circular MSC 253(83) raised by CCS——the srandard of the navigation controller and related devices’ performance. It consists of two serial ports, compliant with the ISO IEC61162, and can send the alarm signal to peripherals, the RS-485 interface can also connect to VDR device to record the data.

Product Picture:

Specifications

Channel: 24 Road /28 Road navigation signal control

Power :24VDC/220VAC

Communication Interface: RS485/RS232 Interface

Operating tempreature: -15℃-55℃

Internal power consumption :10W

Relay output contacts :5A/24VDC 1A/220VAC Load Power

Range :5-100W

Realative humidity :5-95% the non-condensing

Case material :Iron

Case color: black

Hole size :144mm*240mm

Vice-plate size: 412mm*142mm*60mm

Dimensions :165mm*285mm*50mm
