Automatic bus bar processing machine for cutting, bending and punching
- Shanghai
- T/T L/C
- 50 days
You May Like
-
Hydraulic bus bar bending machine, copper bar punching machine
-
Automatic busduct packing machine, packaging line for busway system
-
compact busbar assembly machine, automatic busduct assembly line
-
Mylar film forming machine, Polyester insulation film folding machine
-
Mylar film slitting machine, polyester film cutting machine
-
Joint Connection Bar Processing Center
Product Details
| Brand Name | Kiande | Place of Origin | China | |
| Model Number | KDEQ-E-001 | Certification | Other, Customized machine, all the components can fulfill the relevant requirements. | |
| After-sales Service Provided | Engineers available to service machinery overseas | Condition | New | |
| Machine Type | Beading Machine | Extra Services | Other, cutting, bending, punching | |
| Automation | Automatic | Power | Cnc | |
| Material / Metal Processed | Other, Aluminum, copper | Raw Material | Steel Bar |
Product Description
Busbar Conductor Multifunctional Processing Machine
By busbar conductor multifunctional processing machine, operator will input values such as length, width, piler position, quantity and etc. to initiate automatic working procedures including ends punching, piler opening, piler punching and etc..
No. | Parameters | ||
設備型號Model | KD-DTYTJ-C/A-4.5(6) | ||
公稱力 Force (KN) | 壓彎 Bend | 400 | |
沖孔 Punch | 300 | ||
壓樁頭Piler Head | 300 | ||
X軸行程 Stroke of X Axis | 1800mm | ||
X軸速度 Speed of X Axis | 0~150mm/s | ||
打標Marking | 條碼、二維碼（選項） Barcode, QR code (optional) | ||
導體規格 (銅、鋁) Conductor Size (Aluminum, Copper) | 長Length | 1200mm~6000mm | |
寬Width | 140mm~300mm | ||
厚Thickness | 2mm~6mm | ||
定位精度Positioning Accuracy | 0.2mm | ||
重復定位精度Repetitive Positioning Accuracy | 0.05mm | ||
鋸片功率Saw Blade Power | 2kW | ||
鋸片直徑Saw Blade Diameter | 400mm | ||
最大壓彎寬度Max. Bending Width | 300mm | ||
最大壓彎高度差Max. Bending Height Difference | 40mm | ||
最大液壓力Max. Hydraulic Force | 31.5MPa | ||
電源Power | 380~415VAC 50~60Hz 10kW | ||
