Pipeline Filter DFB-H240*C/DFB-H330*C/DFB-H110*C/DFB-H660*10C High Pressure Plate Filter

Pipeline filter  DFB-H240*C/DFB-H330*C/DFB-H110*C/DFB-H660*10C high pressure plate filter

DFB-H series high pressure plate filter

The high pressure plate filter can be mounted directly on the valve block of the system to further remove or block contaminating particles generated by external intrusion or wear during operation of the component. Especially suitable for automatic control systems and servo systems. It prevents high-precision control components and actuators from rapidly wearing or jamming due to contamination, reducing faults and extending component life.
The filter is provided with a differential pressure signaling device. When the filter element is clogged and the pressure difference between the inlet and outlet ports is 0.5 MPa, the switch signal is issued. At this time, the filter element should be replaced or cleaned to achieve the purpose of protecting the system.
The filter has the characteristics of compact installation structure and small volume. The filter element adopts imported glass fiber filter material, which has the advantages of high filtration precision, large oil passage capacity, small original resistance and large amount of dirt absorption. The filtration precision is calibrated with absolute filtration precision. The filtration ratio is β3, β5, β10, β20≥200, and the filtration efficiency η≥99.5%.

Packaging details
Standard export wooden case or as your requirements
Delivery details
5-10 days after payment

Company Information
1.ZHENYUAN hydraulic equipment Co.,Ltd has more than 30years of experiences in manufacturing CNC
machines, and plastic injection moidingmachines.
2.ZHENYUAN company has quiet office enviroment and we have independent R&D ability.
3.ZHENYUAN commpany has efficient production department and strict quality control department to supply        good quality products all over the world.
Our Advantages
1.Be of long standing factory built in 1986;
2.usa professional engineer and with 5 utility models and 4 patents;
3.GRH OEM and with 370 professinal employees, 4workshops total 22000 square meters;
4.208 pcs mechanical and test equipments:
5.100% factory testing and inspection personnal in accordance with international standards for the high-frequency sampling,to ensure the quality of products manufactured;
6.Become TEREX,JOHN DEERE,HYDAC,AGCO,EATON,NEW HOLLAND,GARONER DENVER and MAHINDRA supplier.

FAQ
Q:What Is Our Main Application?
A:1.Hydraulic system
   2.Agriculture machine
   3.Construction machina
   4.Automobile
   5.Local distributors
Q:What Is The Payment Terms?
A:Full order:30% as desposit, the balance before shipment:
   Small order /sample ordre: full payment in advance:
Q:Can I Mark My Own Brand On The Pump?
A:Yes. Full order can mark your brand and code.
Q:What Is Our Main Export Market?
A:Europe (41.7%):Italy,Germany,England,France,Holland,Greece,Spain,Portugal,Swissland,Finland,Czekh,Russia,Poland
   Asia(40.5%):China,Korea,Singapore,India,Turkey,Iran,Vietnam,Saudi Arabia,Syria,Isreal,Lebanon
Q:How Long Is Guarantee?
A:We give 1 year guarantee.
