TE7001 Transformer Insulation Oil Break Down Test Kit 80KV/100KV

Item: Automatic insulation oil breakdown tester

Model:TE7001/TE7003/TE7006

Product Description

TE7001 Automatic insulation oil breakdown tester is fully digital industrial instrument with microcomputer control. It has the features of high accuracy and strong anti-interference ability.

Features

·         LCD screen display.

·         Mono-chip control, stable and reliable.

·         WDT adopt, no system halted condition.

·         The oil cup is made by once forming special glass to avoid leakage.

·         Over-current, over-voltage and short circuit protection functions, with strong anti-interference ability.

·         Test the one sample, three samples or six samples accordingly at one time.

Specifications

·         Booster Capacity: 1.5kVA

·         Increasing speed: 2.0kV/s, 3.0kV/s

·         Output voltage: 0-80kV/0-100kV

·         Power supply distortion rate: <1%

·         Electrode gap: 2.5mm

·         Dimension: 430*350*370mm

·         Weight: about 26kg.

    Environmental temperature: 0-40℃

·         Relative humidity: ≤85%

·         Power supply: AC220V±10%

·         Frequency: 50±5Hz

·         Power consumption: <200W
