Home > Products > CK500 CNC Lathe > CNC Flat Bed Lathe CK500/2000 Heavy Cutting with Low Noise Chuck Lathe
CNC Flat Bed Lathe CK500/2000 Heavy Cutting with Low Noise Chuck Lathe
US$ 12600 - 12850
/ Set
1 Set(Min. Order)
- Shanghai
- T/T L/C
- 10 days
You May Like
Product Details
| Brand Name | RUNTEEN | Place of Origin | China | |
| Model Number | CK500/2000 | Type | Horizontal | |
| Certification | ISO9001 | After-sales Service Provided | No overseas service provided | |
| Weight | 3200 kgs | Dimension(L*W*H) | 3545*1555*1780 mm | |
| Voltage | 220V/380V/415V | Condition | New | |
| Power(W) | 7.5 kw | Automatic Grade | Automatic | |
| CNC or Not | CNC | Max. Swing Diameter | 500 mm |
Product Description
Product Description
Technical Specifications
| Model | CK500 |
| Max. swing over bed | 500mm |
| Max. swing over slide | 280mm |
| Max. length of the work-piece | 1000mm 1500mm 2000mm |
| Range of the speed | 43-430r/min 170-1700r/min (2 gear stepless) |
| or 170-1700r/min (stepless) | |
| Spindle bore | Φ85mm |
| Taper of bore in spindle | 1:20 |
| Rapid traverse rate | X:3800mm/min Z:7600mm/min |
| Min. feed unit | X:0.0005mm Z:0.001mm |
| Feed motor | Servo motor |
| Main motor power | 7.5kw (frequency conversion) |
| CNC system | GSK980 (or according to customers' requirement) |
| Tool post | 4 station electric tool carrier |
| Net weight | 2.1t / 2.6t / 3.2t |
| Overall dimensions | L: 2545 / 3045 / 3545mm |
| W:1555mm | |
| H:1780mm |
