Robot waterjet cutting machine for metal

FOB Price

USD $32990 - $38990 / Set

1 Set(Min.Order)

Supply Ability 20 Set / Sets per Month
Port QINGDAO
Payment TermsT/T L/C D/P D/A
Delivery Detail30 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	WAMIT	Place of Origin	China
Model Number	WMT2515-AL	Certification	CE
After-sales Service Provided	Engineers available to service machinery overseas	Warranty	one year
Weight	3500KG	Dimension(LWH)	270017001000mm
Voltage	380V/220V/415V	Rated Power	37KW
Condition	New

Product Description

High pressure water jet cutting machine for Acrylic/carbon steel/foam/marble/rubber/glass stainless steel/aluminum/mild steel/granite/brass/ceramic/copper/stone&tile/meat/fiber glass high speed 420Mpa 3 axis CNC with new technology of us can make the machine moving speed to 30M/MIN,so it will reduce your half using cost!

granite and marble cutting machine

Name	Item	Parameter
Intensifier Pump	Model	WMT3742Z
	motor	SIEMENS
	Method of Direction Regulation	Electronic direction regulation
	Pressure Range	50-420MPA, continuous pressure is 330-380Mpa
	Maximum Flow of Hydraulic Pump	90 L/min
	Maximum Discharge Capacity	3.7 L/min
	Maximum Diameter of Gem Nozzle	0.33 mm
	Power of Master Motor	37 KW
	Power Source	380V/50HZ, also work at 220V/60HZ, 415V
Cutting Table	X axis Characteristic	use strong 10MM steel, 3000MM cutting range. The cutting table width is 3200mm
	Y axis Characteristic	Cast iron is used as the foundation base , 2000MM cutting range . The cutting table length is 3200mm.
	Z axis Characteristic	Z axis double linear guide and four sliding block , 180MM, CAN DO 200MM
	Control Accuracy	±0.01mm, cutting accuracy is ±0.1mm, reposition accuracy: ±0.02mm, max travelling speed:6000mm/min, we have new technology that can make the travelling speed 20-30m/min.
	linear guider	TAIWAN TBI BRAND
	Table Ctructure	can be delivered by one 40'FCL container
	Driving Way	Servo drive system
	CNC system	Ncstudio ,Fagor
	Servo Motor	SIEMENS motor
	Cutting Head	Casting structure and Concrete structure
	Sealing Way	soft dustproof cloth on X,Y,Z axis,the sealing result will be better,and there is a oil tank under the cutting table,the linear guider no need maintainence.
	Loading Weight Water Tank	Wall thickness is 6mm,using fluorocarbon coating, Can antirust at least 5 years.
CNC Controller	Control Method	CNC
	Display Size	19inch LCD
	Model of Cutting Text	DXF
	Model of Computer	Industrial Control Computer
	Operating System	Windows 7
	PLC	SIEMENS
	Cutting Software Advantage	Auto save and transfer common parameter
	Controller Displace	Can be fit to suitable place at own will
Automitic Abrasive Feeder	Founction	Sand storage and sand delivery
	Operating	No need electrocnic control,sample operation
	Capacity	200 kg for 8 -10hours
	Pressure	0.3-0.6Mpa compresses gas pressure
	Color	White
Deionization System	Water pressure	0.15Mpa~0.6Mpa
	Water temperature	5°C~50°C
	Environment temperature	5°C~50°C
	Relative humidity	≤95%(25°C)
	Water turbidity	<20FTU
Wireless Handle	Founction	Wireless controlling waterjet
	Display	Real- time display condition of X,Y,Z axis
	Settings	Zero point, on/off valve set, X,Y,Z axis moving
	Technology	Advanced technology

Advantage:

1.37KW SIEMENS motor
2.All electric components are Schneider brand
3.Can do special size and special design according to customer’s demand
4.Free abrasive sand feeding system
5.We have most convenient automatic abrasive sand removing and recycling system for any brand water jet cutting machine
6.Imported intensifier pump
7.Use 8mm steel to make the cutting table stronger and keep the precision time for whole life
8.Soft cover for linear guider or gear and rack, can effectively prevent dust
9.Install an automatic oil tank for cutting table , no need maintenance of linear guider
10.Legitimate WINDOWS 7 system and install the Chinese newest water jet cutting system
11.TBI linear guider and ball screw
12.Variable servo pump can reduce the electricity cost
13.We have agents in America, Russia, South Africa, Ecuador,UK, Argentina, Chile.Mexico,Australia,Saudi Arabia,Malaysia.Vietnam
14.We can make machine moving speed to 10-50m/min which will improve your cutting efficiency
15.We are finding agent all over the world

Models of Bridge type CNC waterjet cutting machineModel numberX Axis(mm)Y Axis(mm)Z Axis(mm)WMT1010-AL10001000150-200WMT1515-AL13001300150-200WMT2015-AL15002000150-200WMT2515-AL15002500150-200WMT2520-AL20002500150-200WMT3015-AL15003000150-200WMT3020-AL18003000150-200WMT4020-AL15004000150-200 WMT4030-AL18004000150-200WMT5020-AL20005000150-200WMT6020-AL20006000150-200WMT8020-AL20008000150-200WMT12020-AL200012000150-200WMT5030-AL30005000150-200WMT6030-AL30006000150-200 WMT8030-AL30008000150-200WMT12030-AL300012000150-200

Models of cantilever type CNC waterjet cutting machineModel numberX Axis (mm)Y Axis (mm)Z Axis (mm)WMT1010-AX10001000150-200WMT1515-AX13001300150-200WMT2015-AX15002000150-200WMT2515-AX15002500150-200WMT2520-AX20002500150-200WMT3015-AX15003000150-200WMT3020-AX18003000150-200WMT4015-AX15004000150-200WMT4020-AX18004000150-200WMT4030-AX20004000150-200WMT5020-AX20005000150-200WMT6020-AX20006000150-200WMT8020-AX20008000150-200WMT9020-AX20009000150-200WMT10020-AX200010000150-200

We have 420Mpa intensifier pump, 600Mpa intensifier pump ,direct drive pump and 420mpa with dual intensifier pump, we also can provide 3 axis , 5 axis with 10 degree and dynamic 5 axis with 60 degree cutting head water jet cutting machine, pure water cutting and abrasive sand cutting. our machines are with excellent quality - efficient and accuracy, economical investment with low initial cost and low maintenance cost to our customers. All the machinery delivered by us come with first class after-sale service. all machines are with one-year warranty of main parts, whole-life after-service for the entire machine.
our new FLOW type cutting head can improve you 10% cutting efficiency, and our new technology can make the machine moving speed to 30-50m/min so that reduce you 15%-50% cutting cost according to the materials.

1. What are the benefits of purchasing a water jet cutting machine comparing EDM, Laser, Plasma or Machine tool?

Requirements	Waterjet	EDM	Laser	Plasma	Machine tools
Cost and time efficient	Yes	No	Yes	Yes	No
High tolerance, precise cutting	Yes	Yes	Yes	No	No
No burned edges, no HAZ	Yes	No	No	No	Yes
Multi-head cutting	Yes	No	Yes	No	Yes
Steel is over 150mm thickness	Yes	Yes	No	Yes	Yes
No distortion or discoloration	Yes	Yes	No	No	Yes
Nesting yield	Yes	Yes	Yes	No	No
Shiny, mirror finish	Yes	Yes	No	No	Yes
Brittle,soft or hard material	Yes	Yes	Yes	Yes	No
Stainless steel, copper, brass or exotic material	Yes	Yes	No	Yes	No
No toxic fumes, deposits, or carbon buildup	Yes	No	No	No	No
Environmentally friendly	Yes	No	Yes	Yes	No

2. What kind of material does your water jet cutting machine can cut?
There are plenty materials our water jet cutting machine can cut, such as stone, ceramic, quartz, glass, foam, plastic, rubber, copper, brass, aluminum, mild steel, pre-hardened steel, titanium, inconel and hastalloy
3. What's your cnc water jet cutting machine's max.cutting thickness?
Generally speaking, if cut steel the max thickness of our water jet cutting machine can be up to 240mm, but we suggest cut not more than 150MM for smooth cutting. now our Z axis distance is 170mm, we can do special for customers.
4. How we supply after-service?
Some countries we have after-service department, we will provide local service, if have no local service, we will arrange engineer for overseas installation and training. The installation and training time is generally 7-10 days. And we also can provide installation videos.
5. What's your delivery time?

Generally speaking is 30 days. if have stock, 15 days.

6. what is the cutting speed?

Material	Thickness(mm)	Cutting Speed of 420MPa pump(mm/min)
Marble	20 30	410 360
Granite	20 30	380 250
Glass Bridck	12	1100
Glass	5 10 20	1610 725 420
Glue Chipped Glass	10	630
Sponge	50	6500
Foam	50	6500
Wood	10 50	1350 270
Steel	2 4 6 8 10 15 20 60	800 570 520 360 260 150 60 26
Laminates	10	2000
Aluminum	5	970
Copper	5	460
Glass Fibre Reinforced plastic	2	1650
