M-200 Portable Gate Valve Grinding Machine Portable Valve Grinding and Lapping Machine

 M-200 Portable Gate Valve Grinding Machine
 Portable Valve Grinding and Lapping Machine
 Applicstion:Gate Valve Seat,Gate Valve Core.
 Grinding scope: DN80~200(3"-8")
 Motor power: 1100W
 Rated Voltages: 220V
 Min distance of valve seal face: B>45mm
 Allowed adjustable length: L≤600mm
 Operating weight: 20kg
 1. Main body 2.electric motor 3.power box 4.adjusting bracket 5.screw bolt 6.base escopic boom
 8.arm 9grinding disc 10screw bolt 11screw bolt 12 clamping rod 13Fastening handle escopic boom lock arm 15.left or right adjusting handwheel 16.handwheel 17.sliding crame 18.screw bolt
 2.OVERVIEW
 Model M-200 portable valve grinder is widely used in the industries such power generation, petroleum, chemical, metallurgy and paper making as a high-tech product with national patent. It has the following characteristics:
 Light, compact, and easy to carry
 Split-type assembly makes installation easy and fast
 Available in various field work
 Applicable in grinding gate, check valves and flanges made of various materials
 Grinding automatically after the installation is adjusted well
 Reasonable structure design, perfect Metabo motor and high-quality imported grinding materials contribute to the grinding 3-10 times as fast as the manual one
 Stepless and adjustable speed, stable power transmission and accurate lapping make the sealing face in complete contact.
 portable valve grinding machines Technical Parameter
 Applicstion:Gate Valve Seat,Gate Valve Core.
 Grinding scope: DN80~200
 Motor power: 1100W
 Rated Voltages: 220V
 Min distance of valve seal face: B>45mm
 Allowed adjustable length: L≤600mm
 Operating weight: 20kg
