3A 1.8 Degree 2 Phase NEMA 23 Waterproof Stepper Motor for Waterjet Engraving Machine
US$ 15 - 30
/ Piece
1 Piece(Min. Order)
- Shanghai Ningbo Shenzhen
- T/T Credit Card
You May Like
-
Competitive Price NEMA 23 Waterproof Stepper Motor for Waterjet Milling Machine
-
High Torque 2 Phase NEMA 23 Waterproof Stepper Motor for Waterjet Cutter
-
Low Price IP65 Waterproof NEMA 34 Stepper Motor for Dusty Environment
-
Waterproof NEMA 34 Stepper Motor for Medical Equipment
-
IP65 Waterproof 2 Phase NEMA34 Stepper Motor for Waterjet Cutter
-
High Torque Watertight NEMA 34 Stepper Motor for Fountain
Product Details
| Brand Name | PrimoPal | Place of Origin | Shanghai, China | |
| Model Number | PHP57S Series | Type | Hybrid | |
| Phase | 2 | Certification | CE, ISO, ROHS, UL | |
| Current / Phase | Variable, can be custom |
Product Description
PHP57S series hybrid stepper motors are supplied by one of the China's top stepper motor suppliers (PrimoPal Motor), which are very popular in the market. These NEMA 23 waterproof stepper motor with 1.8° step angle (200 steps/revolution) are made of high-quality cold rolled steel sheet, anti-high temperature permanent magnet and special process for waterproof seal. The body length of PrimoPal's NEMA 23 IP65 rated stepper motors ranges from 82mm to 102mm, and the holding torque could be as high as 200N.cm (284oz-in). These high-performance and high-reliability water-proof NEMA 23 stepper motors are terminated with four flying ended lead wires, and could be easily connected to the constant current or chopper drive controllers.
| Step Angle | 1.8° |
| Step Angle Accuracy | ±5% (full step, no load) |
| Resistance Accuracy | ±10% |
| Inductance Accuracy | ±20% |
| Temperature Rise | 80 °C Max.(rated current, 2 phase on) |
| Ambient Temperature | -20 °C ~ +50 °C |
| Insulation Resistance | 100 MΩ Min., 500VDC |
| Dielectric Strength | 500 VAC for one minute |
| Shaft Radial Play | 0.02 Max. (450 g-load) |
| Shaft Axial Play | 0.08 Max. (450 g-load) |
| Model | Current | Resistance | Inductance | Holding Torque | Rotor Inertia | Bi/Unipolar | Weight | Length |
| A/Ø | Ω/Ø | mH/Ø | N.m | g.cm2 | # of Leads | kg | mm | |
| PHP57S82-410 | 1.0 | 6.0 | 22.0 | 1.2 | 280 | Bi (4) | 0.65 | 82 |
| PHP57S82-420 | 2.0 | 1.65 | 5.7 | 1.2 | 280 | Bi (4) | 0.65 | 82 |
| PHP57S82-430 | 3.0 | 0.74 | 2.4 | 1.2 | 280 | Bi (4) | 0.65 | 82 |
| PHP57S102-420 | 2.0 | 2.5 | 9.7 | 2.0 | 480 | Bi (4) | 1.05 | 102 |
| PHP57S102-430 | 3.0 | 1.15 | 4.4 | 2.0 | 480 | Bi (4) | 1.05 | 102 |
| PHP57S102-440 | 4.0 | 0.65 | 2.5 | 2.0 | 480 | Bi (4) | 1.05 | 102 |
Note: We also could manufacture the custom stepper motors, according to the customer's requirements.
