Nickel Alloy Sheet Astm 4J29 Precision Alloy Steel Plate
- shanghai port
- T/T Credit Card
You May Like
-
4J29(Kovar),4J32,4J33,4J34,4J36(Invar),4J50 Capillary Tube
-
China Manufactory Uns N07090 Bar Rod A312 UNS S21800 Alloy Nitronic60
-
Incoloy MA956 Alloy Steel Forged Round Bar Price
-
Nickel Based Alloy Pipe Alloy 200 201 2.4068 Alloy Steel Pipe Tube
-
W.nr.2.4066 Nickel Alloy 200 Bar
-
W.Nr.2.4066 Ni99.2 Pure Nickel Metal Smooth Annealed Plate
Product Details
| Brand Name | cunrui | Place of Origin | China | |
| Model Number | 4j29 | Type | Nickel Plate | |
| Application | many kinds of industry field | Grade | Nickel Base Alloy | |
| Powder Or Not | Not Powder | Ni (Min) | 28% |
packed with waterproof paper or weave bag, into pallets or wooden case.
Product Description
Product Description
nickel alloy sheet astm 4J29 precision alloy steel plate
Grade and chemical composition | ||||||||||||
Grade | Mass fraction (%) |
| ||||||||||
C | P | S | Mn | Si | Cu | Cr | Mo | Ni | Co | Fe |
| |
≤ |
| |||||||||||
Kovar | 0.03 | 0.020 | 0.020 | 0.5 | 0.30 | 0.20 | 0.20 | 0.20 | 28.5~29.5 | 16.8~17.8 | Balance |
|
tensile strength for strips | |
Status | tensile strength /MPa |
soft | <570 |
hard | >700 |
hardness of strip in deep punching status | ||
status | thickness/mm | Hardness Hv |
deep punching | >2.5 | ≤170 |
≤2.5 | ≤165 | |
coefficient of linear expansion | |||||
Grade | heat treating regime | a/(10-6/K) |
| ||
20~300°C | 20~400°C | 20~450°C |
| ||
Kovar | Heat the sample to 900±20°C in hydrogen atmosphere, keep the temperature for one hour, heat again to 1100±20°C and keep the temperature for 15min, then cool to below 200°C at the speed ≤5°C/min and discharge. |
| 4.6~5.2 | 5.1~5.5 |
|
4.3~5.1 | 4.6~5.2 |
|
| ||
coefficient of expansion | |||||||||
Grade | Average coefficient of expansion a/(10-6/K) |
| |||||||
20~200°C | 20~300°C | 20~400°C | 20~450°C | 20~500°C | 20,600°C | 20~700°C | 20.800°C |
| |
Kovar | 5.9 | 5.3 | 5.1 | 5.3 | 6.2 | 7.8 | 9.2 | 10.2 |
|
