NTS205 The Best Price CRI Tester Common Rail Injector Test Bench From Manufacturer

Common Rail Injector Test bench  EPS205/NTS205

The common rail injector test bench is our latest independent researched special device to test the performance of high-pressure common rail injector, controlled by industrial computer, Windows operating system. The oil quantity is measured by sensor and displayed on computer screen(Electronic fuel delivery system). All data can be searched and saved. It adopts BOSCH original common rail pump to provide 0~2000 bar for rail pressure. The rail pressure can be adjusted automatically, and it also provide pressure overload protect. It can test common rail injector of BOSCH, SIEMENS, DELPHI, DENSO. Advanced technology, steady performance, precise measurement and

 >>>CHARACTERISTIC

1. Controlled by industrial computer in real time, Windows operating system.

2. Oil quantity is measured by sensor and displayed on 10.4 tactile  LCD screen;

3. More than 700 kinds of injector data can be searched and used.

4. It is installed BOSCH common rail pump to provide 0~2000 bar

5. Rail pressure can be tested in real time,

6. Provide pressure overload protect

7. Pulse and frequency of the injector can be adjusted.

8. Injection time can be set.

9.  Protection function of short-circuit.

10. Precise measurement, easy operation, low noise.

11.Frequency converter inside to keep the RPM.

 >>>FUNCTION

1.Test injector brands:BOSCH, SIEMENS, DELPHI, DENSO.

   Piezo injector testing(option function)

2. Test 1 piece of injector.

3. Test the Leakage performance of common rail injector.

4. injection oil quantity and back oil quantity(pre-injection, Idling, emissions, full load)

5.Electronic fuel delivery measuring,  automatic testing and detection.

6. Data can be searched and saved.

>>>TECHNICAL PARAMETER

1. output power:1.5KW

2. power voltage:220V 1phase

3. motor speed: 0-3000RPM

4. Oil pressure:0-2000bar

5. flow measure range: 0-600ml/1000times

6. flow measurement accuracy: 0.1ml

7. temperature control range: 40+-2

Tai'an Dongtai Machinery Manufacturing Co.,LTD  is  located at the foot of Mount Tai "Five Sacred Mountains Domination" . Company use advanced production and processing equipment and full set of production technology and product design software . Produce of Auto testing and test equipment with the world advanced level,have more than 100 employees. Chinese first engineers, technicians major in Frequency fuel pump test stand, spare parts,Auto maintenance and computer fields
Main products include:
     1.Diesel engine parts (nozzle, plunger, delivery valve, head Rotor, injector, fuel pump and other accessories); 2.Injection pump test bench; 3.auto tools; 4.Auto parts; 5.special vehicles; 6.Turbocharger.......
     Production process using advanced computer control and digital display systems, production technology, strong technical force . High quality, high technical performance, with micro-controller and digital functions. Products are sold  more than 100 countries and regions of all world .

Our spirit is "excellent quality, excellent price, excellent service " three excellent operating principle of dedication to customer service, for the development of the internal combustion engine testing industry Chinese and abroad to make greater contributions.
