XYD-3 trailer mounted core drilling machine / core rig
- 100 Set / Sets per Month
- Qingdao
- T/T L/C
You May Like
-
XY-100 hydraulic core drilling rig is widely used for core drilling rig
-
xy-150 Water well drilling rig construction foundation survey drilling machinery
-
XY-200 Borehole Drilling Diamond Core Sample Machine Artesian Well Water Well Drilling Rig
-
XY-180 hydraulic water well drilling rig diamond core drilling rig for sale
-
XY-8 rock Core Drilling Rig Diamond Rock Boring Machine On Promotion
-
XY-44A Hydraulic pressing machine deep water well drilling rig for sale
Product Details
| Brand Name | Master Machinery | Place of Origin | China | |
| Model Number | xyd-3 | Type | Core Drilling Rig | |
| Certification | iso-9001 | After-sales Service Provided | Engineers available to service machinery overseas | |
| Warranty | Six Months | Weight | 1800kg | |
| Dimension(L*W*H) | 2500×900×1800mm | Power Type | Diesel | |
| Usage | Ore | Condition | New | |
| Power(W) | Diesel |
Product Description
Characteristic of XYD-3 crawler core drilling rig
XYD-3 crawler drilling rig is mainly used for geological general investigation and exploration,road and tall building foundation exploration,kinds of hole in concrete structure,river levees,subgrade grouting hole drilling and direct grouting,civil wells and earth temperature central air-conditioner,ect.
a.The machine is equipped with crawler chassis device, easy to move with fast speed.
b.The crawler device is made of very resistan steel mill.
c.Hydraulic oil pressure feed device, improves drilling efficiency.
d.Pressure gauge display the condition of the bottom of the drill hole.
e.Drill mast controlled by hydraulic cyliner, improve the efficiency.
f.Diesel engine adopt the electric starter, to reduce the labor intensity.
2. Parameters of XYD-3 crawler core drilling rig
Drilling depth | 600m |
Max. open hloe caliber | 300mm |
End hole caliber | 75mm |
Drilling rod diameter | 60mm |
Drilling angle | 90°~75° |
Spindle | |
Spindle forward speed | 30-1050r/min |
Spindle reverse speed | 29-137r/min |
Spindle stroke | 600mm |
Spindle inner diameter | 96mm |
Main Winch | |
Single line lifting speed | 0.5,0.9,1.4,1.9m/s |
Diameter of wire rope | 12.5mm |
Brake width | 90mm |
Drum diameter | 300mm |
The biggest single rope hoisting capacity | 30KN |
Mud pump | |
Type | Horizontal triples BW-250 Mud Pump |
Displacement | 250L/min |
Water inlet diameter | 75mm |
Water outlet diameter | 50mm |
Power | |
Diesle engine | 38KW |
Electric motor | Y180L—4 22KW |
weight | 6500kg |
Size | 2500×900×1800mm |
