HPC008

Size

18.9(L)*14.5(W)*5.8(H)CM

Processor

ARM cortex A7>1GHz（28nm）

Sensor

Video Input

cmos /Simplex high definition

Video Compression standard

H.264, YUY2

Video Definition

Adjustable

Image Processing

Exposure Control/ Gain Control/  White Balance/ Gamma Correction

Video Frame rate

30fps

Measuring Range

2m

Installation Height

2.5-5.0m

Port protocol

Network Interface

RJ45, 10M/100M, Adaptive to Ethernet port

Protocol Standard

802.11a or 802.11b/g

Maintenance Interface

Micro USB

SD card

Built-in, 8G～32G

Electronic Clock

Built-in, RTC module

Remote Upgrade

Upgrade By The Website

Physical Parameter

Size

120mm*120mm*48mm

Weight

200g

Adapter

+5V/2A

Power

≤10W/ POE optional

Hardware Monitoring

Hardware Watchdog

Temperature

-20℃～+65℃

HPC008-2.1

2.6--2.7 M

HPC008-2.5

2.8--3.0 M

HPC008-2.8

2.9--3.2 M

HPC008-3.6

3.2--3.8 M

HPC008-4

3.9--4.4 M

HPC008-6

4.4--5.1 M

The critical height, advised to choose a large lens

Remark

This test results is based on persons of average 1.7M

Effective width detection 2M

Data Safety

1. Network-off protection: The data can be saved in the device for 10,000 seconds (about 3 hours), even there is no network.
2. The data can be exported in PNG, JPG, PDF form.
3. Data backup: When the IP address is changed, the data can be backed up.

Data Transmission

1. The data can be transferred to server directly.
2. It can work in WiFi network.

Data Report

1. Detailed valid in-out-stay data.
2. Data from different entrances in different shops can be distinguished.
3. Sales info can be inputted manually. It is convenient for shop to make the commercial solution.
4. With a API, the data can be integrated into POS/ ERP system.

Power Supply

Adapter or POE as your requirement.
