XY-180 Large diameter 100-meter geological exploration core drilling machine water well drilling rig
- 100 Set / Sets per Month
- Qingdao
- T/T L/C
You May Like
-
XY-200 water well drilling rig hydraulic core drilling machine building foundation survey equipment
-
Diamond rope coring drilling rig hydraulic exploration drilling machine in metal mine tunnel
-
Metal mine full hydraulic steel obtained core prospecting rig
-
KY-250 Water and gas exploration drilling rig/metal exploration drilling rig
-
KY-300 tunnel core drilling rig underground mine water well drilling rig
-
KY-6075 Water and gas exploration drilling rig/metal exploration drilling rig
Product Details
| Brand Name | Master Machinery | Place of Origin | China | |
| Model Number | xy-180 | Type | Rotary Drilling Rig | |
| Certification | ISO-9001 | After-sales Service Provided | Engineers available to service machinery overseas | |
| Warranty | Six Months | Power Type | Diesel | |
| Usage | Water Well | Condition | New | |
| Power(W) | Diesel |
Product Description
1.The main charateristic of XY-180 water well drilling rig
a.The XY-180 drill is designed on the basis of the XY-150 drill. It is a low speed and high torque portable drilling machine with oil pressure.
b.This drill is suitable for engineering geological survey of railway, hydropower, traffic, bridge, dam foundation and other buildings.
c.Geological core drilling and physical investigation.
d.Drilling holes for small holes and blasting holes.
e.A small water well drilled.
2.The technical parameter of XY-180 drilling rig
Drilling depth（m） | 180,150,120,90,70,30 |
Borehole diameter（mm） | 75,91,110,130,150,300 |
Maximum opening diameter（mm） | 375 |
drill pipe diameter（mm） | 42、50 |
Spindle Speed (r/min) | 71,142,310,620 |
SpindleStroke（mm） | 450 |
Upgrading Ability (KN) | 15 |
Diameter of steel wire（mm） | 12 |
Type | gear pump |
Model | YBC-12/80 |
Rated pressure (MPa) | 8 |
Rated speed (r/m) | 1500 |
Displacement（ml/r） | 8 |
Power supply | ZS1115 diesel engine and 15kw motor |
