Common Rail Injector and Pump Test Eps 708 Common Rail Test Bench CR815

                        Factory supply common rail injector tester diesel fuel pump test bench cr815

 CR815 common rail injector and pump test bench, use import the flow sensor for the measurement means, it can test common rail injector and common rail pump, it can add EUI/EUP CAMBOX and HEUI function. The device uses high-power inverter and motor, heavy plate casting table for different power and torque of the common rail pump test. It can test Bosch, Denso, Delphi, Siemens, CAT and other brands of electronic control fuel injector, oil flow measurement using imported flow sensor. Measurement parameters, rail pressure, speed, temperature, fuel, computer display. Common rail pump test, the test bench is another major function. Through the pump flow sensor, you can test the maximum common rail fuel supply, economic oil supply, has been zero for the detection of oil, and other technical indicators. The test bench has independent diesel active oil supply system, the pressure size can be adjusted with different adapters, can increase the EUI/EUP and HEUI testFunction

                                                          Technical parameter

 1. Rated output power: 7.5KW ,11KW,15KW,18.5KW (on request)

2. Electronic power: 3PHASE 380V 50HZ OR 3PHASE 220V 60HZ 3. Motor speed: 0-4000RPM 4. Pressure adjustment: 0-2500bar 5. Fuel temperature: 40 ±2℃ 6.Flow testing range:0-600ml/1000times 7.Flow measurement accuracy:0.1ml 8. Filter accuracy: less than 5um 9.Cooling system: fan or forced cooling 10. Fuel tank capacity: 60L 11.. Size: 1900MM * 900MM * 1500MM 9. Weight: 800kg 10. With 19-inch display 11. Adopt interference-free Logitech mouse

result
