T8231 Power Pack P8231

T8231, T8231C, P8231

T8231 Power Pack

Description

The Trusted Power System is a high density flexible power supply designed to convert main line voltages of either 110V or 240Vac. Outputs are either 24Vdc for Trusted product or 28Vdc adjustable field power.

The Trusted Power System consists of a 1U Power Shelf with mechanical support, containing up to three 750W Power Packs. The Power Packs load share in configurations using one or more Power Shelves. Each Power Pack has an individual supply connection via a mechanically retained IEC320 type connector. Each Power Shelf can supply 2250Watts of power or 1500Watts with n+1 redundancy from a single source. Multiple units can be connected for further capacity or redundancy requirements.

Diagnostics information of Power Pack status is provided via the Power Port, which connects to the rear of the Power Shelf. This device monitors input and output conditions and reports out of range faults and over temperature/fan failure using relay contacts. The Power Port also allows connection of the optional rack mounted Power Controller for live configuration of output voltage and current, monitoring up to 12 Power Packs in 4 Power Shelves.

Features

Redundant and N+1 configurations

Hot replaceable power Packs

Current sharing

Current limiting

Power factor correction

Diagnostics contacts

Configurable output voltage

Input/output fail diagnostics per power pack
