Atlas Copco Hydraulic Drilling Rig CM 765 and CM 785 Drilling Rig Machine With Drill Best Prices
- Qingdao /Shanghai/Guangzhou
- T/T Credit Card
You May Like
-
Atlas Copco Drilling Rig Accessories
-
R55-3 Main Hydraulic Pump AP2D25LV P/N 31M6-50031
-
A4VG40 A4VG56 A4VG71 A4VG90 Hydraulic Pump Pump Parts
-
A10VD43 Excavator Hydraulic Pump Assy for SH75/70B/SH60/K'ATO250/307, Pc75uu-2 Hydraulic Pump
-
Rexroth Pump AP2D18 AP2D25 AP2D36 Hydraulic Pump
-
PUMP A7V20 A7V28 A7V40 A7V55 A7V58 A7V80 A7V78 A7V107 A7V117 A7V160 A7V250 A7V500 Hydraulic Piston A7V Pump
Product Details
| Brand Name | Atlas copco drilling rig accessories | Place of Origin | Japan | |
| Model Number | t40 |
Product Description
Atlas Copco Hydraulic Drilling Rig
CM 765 and CM 785 drilling rig machine with best prices
| Technical Data | CM 765 | CM 785 |
| Hole Diameter Range | 102-152mm | 110-171mm |
| Drill Depth(5m) | 76,89,102mm | 89,102mm |
| Drill change Power | 7+1 | |
| Drill depth | 39.4mm | |
| Hammer Size | 4" or 5" | 4",5" or 6" |
| Hydraulic Rotary Head | DDRH-A | DDRH-C |
| Rotary Speed | 0-120 rpm | 0-80 rpm |
| Max FN | 4067 Nm | 6100 Nm |
| Diesel Engine | CAT C11 | CAT C13 |
| 1800rpm Rated Power | 287 kw | 328 kw |
| Exhaust Standard | Stage 3 Tier III | |
| Volume | 568 I | |
| Max Work Pressure | 25bar | |
| FAD Capacity | 298 I/S | 405 I/S |
| Type | Single-Line | |
| Forward Type | Oil Cylinder | |
| Total length of Forward beam | 9500mm | |
| Forward Journey | 5600mm | |
| Forward Support | 1150mm | |
| Max Forward Speed | 0.88m/s | |
| Max Forward Power | 34.5kN0.878m/s | |
| Max Drawing Force, | 67.6kN | |
| Max Moving speed | 3.2km/h | |
| Engine Power | 125.4kN | |
| Climing | 30° | |
| Swing | ±10° | |
| Gap to ground | 432mm | |
| Net Weight | 22200kg | 22700kg |
| Width | 2500mm | |
| Length | 12100mm | |
| Height | 3300mm | |
About us
We are Jining Qianyu Commercial & Trade Co., Ltd. from China, We can supply spare parts with different models as you like.
Q1:Could you custom products?
We can manufacture it according to your drawings or samples.
Q2: I want to buy your products, how can I pay?
A :You can pay via T/T , WEST UNION or other payment terms we reach agreement.
Q3: How can you guarantee the quality?
A: One year's warranty against B/L date.
If You meet with quality problem, we promise to responsible for it.
Q4: If we don’t find what we want on your website, what should we do?
A: You can email us the descriptions and pictures of the products you need, We will check whether we can make it.
Q5: Can we buy 1 pc of each item for quality testing?
A: Yes, we understand quality test is important and we are glad to send 1pc for quality testing.
Q6: What is the lead time?
A: For this product, normally 3 days,3 days and lead time is calculated from the day we receive your deposit.
Exact time is determined by factory schedule.
Welcome all customers to visit our website and cooperate in the future .
If you need our products,pls advice your machine brand&model,or offer the Part No. Thank you!
