Food Grade Composite Flexible Hose
- 20000 Meter / Meters per Month
- Tianjin,Shanghai,Shenzhen
- T/T L/C
You May Like
-
Rotary/drilling hose 5000psi high pressure for oil field
-
High Pressure Rubber Mud Drilling Rig?Hoses/Kelly?Hose10000PSI
-
flexible rubber?hose?for?cement?mud?sand blasting
-
high pressure rotary vibrator?hose?with API certificate
-
API 16C High pressure flexible?kill and choke?hose line
-
API 7k?15000PSI high?pressure?rotary?hose
Product Details
| Brand Name | HUIYA | Place of Origin | China |
Product Description
Food Grade Composite Flexible Hose
PRODUCT PARAMETERS
The composite hose is a hose composed of a variety of polymer materials reinforced layer, a sealing layer and an external anti-wear and anti-aging layer. It is wound by a computer-assisted "labyrinth" seal and fastened by internal and external spiral wire support. And it is originated from Europe and is the latest generation of safe petrochemical hose.
Structure:
Inner steel wire: SS304, SS316 wire
Composite layer: Thermoplastic film.
Outer layer: PVC coated fabric.
Outer steel wire: SS304, SS316 wire.
Our company specializes in producing High pressure hoses, Hydraulic hoses, SAE & DIN series hoses, Drilling Rotary hose, Choke & Kill Line, Bop hoses, Suction and Discharge hose, Fabric hoses, Metal Flexible hose, Fireproof hose, Silicone hose and Hose Assembly, Kelly Hose, etc.
Inner Diameterinch-mm | Max Working PressureMpa | Min Bend Radiusmm | Weightkg/m |
1"-25 | 1.6 | 200 | 1.40 |
1 1/2"-40 | 1.6 | 200 | 1.80 |
2"-50 | 1.6 | 225 | 2.25 |
2 1/2"-65 | 1.6 | 225 | 3.00 |
3"-80 | 1.6 | 350 | 4.20 |
4"-100 | 1.6 | 400 | 4.90 |
6"-150 | 1.6 | 575 | 12.9 |
8"-200 | 1.6 | 800 | 20.5 |
10"-250 | 1.6 | 1000 | 27.5 |
12"-300 | 1.6 | 1200 | 32.8 |
