Sunbun 650T 20L plastic bucket making high presssure plastic injection molding machine

FOB Price

USD $1 - $2 / Set

1 Set(Min.Order)

Supply Ability 2000 Set / Sets per Month
Port Ningbo
Payment TermsT/T L/C
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Sunbun	Place of Origin	China
Model Number	SK140	Certification	CE UL ISO9001
Plastic Type	Thermoplastic	After-sales Service Provided	Engineers available to service machinery overseas
Condition	New	Power(W)	14
Automatic	Yes	Opening Stroke	430
Clamping Force	1400	Injection Rate	131 cm3/s
Injection Weight	267	Style	Horizontal
Type	Preform Injection

Product Description

IT'S 9102 YEAR !

ARE YOU STILL USE TRADTIONAL INJECTION MACHINE ???

SUNBUN SK SERIES CENTRAL LOCKING STRUCTURE HIGH SPEED , HIGH PRECISION INJECTION MOLDING MACHINE

FROM 140T-2800T WE SUPPLY YOUR BEST THERMOPLASTIC INJECTION SOLUSTATION

WITH SMALLER MACHINE MAKE BIGGER PRODUCT ,

WHAT IS WHAT WE GOOD AT .

Company Information

Zhejiang Sunbun Intelligent equipment Co., Ltd (2002 ). is the banch company of Zhejiang Sunbun group (1993). which is the national level high -tech exterprise for heavy equipment hydraulic components system ,valve ,valve board and acturtor of construction.

Sunbun group now have Hangzhou, Wenzhou , Shanghai, Xuzhou 6 production base in China. For injection machine at wenzhou Binhai industrial zone

Now Sunbun have normal servo motor injection machine, High speed machine, Medical machine, PET/PVC machine, Satationery machine ...

SK series is central locking structure machine. It enjoy big clamping force, big open stroke structure , material saving feature.

Start from 140T- 2800T welcome all the clients inquire .

Machina Paramater

Inject type	Unit	SK230/C760
Screw type		A	B	C
Screw dia	Mm	45	50	55
Screw dia ratio	L/D	22	22	20
Injection volume	Cm3	381	471	570
Injection volume (ps)	G	347	428	530
Max injection rate to air	Cm3/s	167	207	250
Injection pressure	Mpa	199	161	133
Injection stroke	Mm	240
Max injection speed	Mm/s	111
Screw max speed	R/min	221

Clamping force	Kn	2300
Open stroke	mm	550
Bar distance	Mmxmm	580x530
Max mold	Mm	560
Min mold	Mm	220
Ejector stroke	Mm	160
Ejector force forward	Kn	70
Ejector force backard	Kn	45
Thimble qty	Pcs	1+12

System pressure	Mpa	16
Motor power	Kw	22
Heater power	Kw	12.65/14.25
Tem control zone qty	Pcs	1+4
Bucket capacity	Kg	50
Oil tank capacity	L	290
Size	M	5.9x1.6x2.1
Weight	T	7.2
