High Power Industrial 4g/5g Wireless Router

Chipset

ARM Cortex-A7 IPQ4018/28,CPU main frequency is 600Mhz

RAM

Defualt DDR3:256MB, Max. 256MB

FLASH

Defualt 32MB, Max. 128MB

Wireless Speed Rate

2.4G:2T2R:300Mbps

5.8G:2T2R:866Mbps

Working Frequency

2.4Ghz/5.8Ghz

Interface

Supports 1 10/100/1000M self-adaption WAN with auto flip (Auto   MDI/MDIX)

Supports 4 10/100M/1000 self-adaption LANs and auto flip (Auto   MDI/MDIX)

Support 1 CONSOLE port for easy debugging; default is not   posted

Support 1 2.0 USB

Support 1 3.0USB

4G/5G

4G/5G design 3.0 USB wire, support 4GMINI-PCIE/M2 sharing,   support 2/3/4/5G,

Max. Power Consumption

<15W

Dimension

165X116X19MM(LXWXH)

Working Environment

Working Temperature: -30 ° C to 75 ° C

Storage Temperature: -40 ° C to 100 ° C

Working Humidity: 10% to 90% RH does not   condense

Storage Humidity: 5% to 90% RH does not   condense

RF(Typical)

11A HT20

11A HT40

11A HT80

MCS0/8    23dB±2dB

MCS0/8    23dB±2dB

MCS0/8    23dB±2dB

MCS1/9  23dB±2dB

MCS1/9  23dB±2dB

MCS1/9  23dB±2dB

MCS2/10 23dB±2dB

MCS2/10 23dB±2dB

MCS2/10 23dB±2dB

MCS3/11 22dB±2dB

MCS3/11 22dB±2dB

MCS3/11 22dB±2dB

MCS4/12 22dB±2dB

MCS4/12 22dB±2dB

MCS4/12 22dB±2dB

MCS5/13 22dB±2dB

MCS5/13 22dB±2dB

MCS5/13 22dB±2dB

MCS6/14 21dB±2dB

MCS6/14 21dB±2dB

MCS6/14 21dB±2dB

MCS7/15 20dB±2dB

MCS7/15 20dB±2dB

MCS7/15 20dB±2dB

Sensitivity

11A HT20

11A HT40

11A HT80

OFDM 6Mbps≤-89

MCS0/8≤-83

MCS0/8≤-80

OFDM 9Mbps≤-88

MCS1/9≤-80

MCS1/9≤-77

OFDM 12Mbps≤-85

MCS2/10≤-78

MCS2/10≤-75

OFDM 18Mbps≤-83

MCS3/11≤-75

MCS3/11≤-72

OFDM 24Mbps≤-80

MCS4/12≤-71

MCS4/12≤-68

OFDM 36Mbps≤-75

MCS5/13≤-67

MCS5/13≤-64

OFDM 48Mbps≤-71

MCS6/14≤-66

MCS6/14≤-63

OFDM 54Mbps≤-70

MCS7/15≤-65

MCS7/15≤-62

Wireless Security

Wireless security function switch;

64/128/152 bit WEP encryption;

WPA-PSK/WPA2-PSK, WPA/WPA2 security   mechanism;

WPS fast security settings

Software Features

Support AP, router,   relay, 4G function, etc.

Support VPN   security tunneling function,

Support dynamic   routing and static routing

Convenient WEB   configuration

Wireless settings   and encryption

Support telnet   management, easy to use console shell interactive environment

Support multiple   dialing methods: automatic allocation, specify IP, specify local peer IP,   ppoe

Support local   software upgrade; support configuration export import, and web online update   firmware

Support operating   system Windows XP/7/8/9/10/Linux
