Hot Dipped Galvanizing Welded Seamless Pipe Fitting Used For Electricity

Hot Cheaper Din2615 Seamless Tee . It is mainly used to either combine or split a fluid flow. Most common tees have the same inlet and outlet sizes, but reducing tees are also available. As a professional pipe tee manufacturer in China, we can provide high quality straight tees and reducing tees to worldwide customers. According to the type of raw material, our product can be sorted into carbon Steel Tee, Stainless Steel Tee, alloy steel tee, high-strength steel tee(Line pipe tee), low-temperature steel tee, and so on. Relying on superior quality and low price, our products are very popular in Italy, Germany, Spain, France, Russia, the United States, Brazil, Iran, India, and some other countries.

Buttweld Pipe Tee Production Range – Equal Tee, Unequal Tee (Reducing Tee)

Outside Diameter: Seamless Pipe Tee ( 1/2″~24″), ERW / Welded / Fabricated Pipe Tee (1/2″~48″)

Types: Equal Tees, Reducing Tees

Wall Thickness: 3mm – 40mm / SCH5, SCH10, SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS

Value Added Services: Hot Dipped Galvanizing, Epoxy & FBE Coating, Electro Polish, Sand Blasting, Threading, Soldering

Production Grades: Stainless Steel, Alloy Steel, Duplex, Nickel Alloys, Low temperature Steel, Carbon Steel, Cupro Nickel

Manufacturing Standards – Pipe Tee

ASME: ANSI B16.9, ANSI B16.28, MSS-SP-43
DIN: DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN: EN10253-1, EN10253-2

ASTM A403 – ASME SA403 – Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings

ASME B16.9 – Factory-Made Wrought Fittings Buttwelding

ASME B16.25 – Buttwelding Ends ASME B16.28 – `Wrought Steel Short Radius Elbows and Buttwelding Returns`

MSS SP-43 – `Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications

stainless steel cross, carbon steel cross and alloy steel cross fittings, commonly known as a 4-way pipe fitting. Cross tee usually generates high stress on pipe as temperature changes, because they are at the center of four connection points. In comparison, a tee is steadier than a cross, as a tee behaves like a three-legged stool, while a cross behaves like a four-legged stool.
