Home > Products > Hot Press Machine > 15 Layers Veneer Hot Press Dryer Machine Plywood Veneer Drying Machine
15 Layers Veneer Hot Press Dryer Machine Plywood Veneer Drying Machine
- 1500 Set / Sets per Month
- Tianjin
- T/T L/C
- 25 days
You May Like
Product Details
| Place of Origin | China |
Product Description
15 Layers Veneer Hot Press Dryer Machine Plywood Veneer Drying Machine
KEY: hot press breath type veneer dryer、Plywood Veneer Drying Machine、Veneer Dryer Production Line
Key Features:
This is hot press breath type veneer dryer, he hot platens are solid platens like hot press machines,and the surface of the platens are milled with grooves,so the water will come out soon after press . This structure makes it very efficient and productive,its drying capacity is 35m3/ day 24 hours .We have many customers in Indonesia and India using Plywood Veneer Drying Machine .
Veneer Dryer Production Line can be heated by steam water or oil,so you can use steam boiler or oil boiler,and you can burn waste wood to heat the boilers. Cost is very low.
Technical Specification:
Model No | BG137x270x15L |
Layer Quantity | 15 Layers |
Hot Platen Quantity | 16 pcs |
Hot Platen Size | 1370x2700x42 mm ,Solid Platen |
Distance Between Layers | 60mm |
Cylinder Size | φ180x900mm |
Cylinder Quantity | 2 Units |
Nominal Pressure | 40 KN |
Hydraulic Rated Pressure | 8 Mpa |
Closing System | Synchronizing Close |
Closing Time | 15 s |
Heating Medium | Thermal Oil or Steam Water |
Boiler Capacity Required | 0.5T Steam Boiler or 300000Kcal Oil Boiler |
Temperature Required | 160℃ |
Drying Capacity | 35 m3/24 hours |
Final Moisture After Dry | 6%-10% |
Motor Power | 13kw |
Frame Structure | Bolting Knockdown Type |
Operating Workers | Four Workers Can Operate Two Units Dryer |
Dimension | 3290x1370x2875 mm |
Weight http://www.articleconstruction.icu http://www. http://www. http://www. http://www. http://www. http://www. http://www. http://www. | 25000 kg |
