Mid-speed Traction Belt Corrugator Belt High Temperature Resistant Conveyor Belt

Mid-speed Corrugator belt Traction Belt

Introduction

Shengyuan weaving belts f single weft and multi-layer warps are widely used in the corrugated board production lines. Our products are:

1.Enhanced high-speed corrugator belt with low noise JWSD: Suitable for average linear speed 300m/min

2.High-speed corrugator belt with low noise WSD-9G: Suitable for average linear speed 200m/min

3.Mid-speed corrugator belt WSD-10Z: Suitable for average linear speed 130m/min

4.High-speed corrugator belt with Kevlar(low noise) KWSD-95G: Applicable to the corrugating equipment which cardboard width is changed often

5.Traction belt/Stack belt QYD/WDD: Belt width (250-2000)mm

6.Pneumatic conveying belt: Belt width (200-3000)mm

Manufacture various kinds of industrial belts according to customers’ requirements.

Products Features

1.Tensile strength: warp direction (63-75)Mpa in dry mode

2.Heat resistance: raw materials are polyester synthetic fibers, softening point ≥260℃

3.Moisture absorption: quick absorption and emission of heat, therefore cardboard can be quickly dried

4.Air-permeability: up to 2.2m3/㎡ min, under 40mm water column pressure, through CCEP test

5.Seams: belt seam part is fabricated with imported steel fasteners and filled with rubber, flat surface, heat-resistance, fastness and non-marking

6.Suitability: suitable for all types of corrugators, various cardboards and some particular operation mode

7.Geometrical dimension: steady belt dimension, high weaving density, low stretching and contraction and good contact between belt surface and cardboard

8.Service life: as long as the same products imported abroad
