Home > Products > A4VTG hydraulic pump,fluid machine valve,ger box and parts > Rextoth A4VTG Hydraulic Hyraulic Pump ,valve,ger Box and PartsA4CSGA2FM?A4VTG?
Rextoth A4VTG Hydraulic Hyraulic Pump ,valve,ger Box and PartsA4CSGA2FM?A4VTG?
US$ 100 - 20000
/ Box
1 Box(Min. Order)
- GUANGZHOU
- T/T
- 7 days
You May Like
Product Details
| Brand Name | Rexroth | Place of Origin | China | |
| Model Number | A4VTG? | Type | Hydraulic Power Units |
Product Description
| product number | Control mode | Specifications | Working pressure | Characteristic | ||||||
| A4VTG | HW1 - Hydraulic proportional control, mechanical servo, rear handle type hexagonal shaft; | 71090 | Nominal pressure:40MPa, peak pressure: 45MPa . | Swashplate design axial piston variable displacement pump for hydrostatic transmission in closed circuit The flow rate is proportional to the driving speed and displacement. With the increase of the angle of the swashplate from zero to its maximum, the flow rate increases. When the swashplate passes through the middle, the direction of hydraulic oil flow will change smoothly. High-pressure oil outlet is equipped with two pressure relief valves to prevent static transmission (pump and motor) from overloading. High pressure relief valve can also be used as a filling valve. Built-in refueling pump acts as feed pump and controls pressure supply; Maximum filling pressure is limited by built-in filling relief valve. | ||||||
| EP3 - Electric proportional control with emergency start and spring reset U = 12VDC | ||||||||||
| EP4 - Electric proportional control with emergency start and spring reset U = 24VDC | ||||||||||
| A-High Pressure Relief Valve with Direct Control | ||||||||||
| Safety instructions： | Pressure nozzle: | |||||||||
| 1、A4VTG pump is designed for closed circuit. -Project planning, assembly and commissioning of axial plunger components must be carried out by qualified personnel. | 2、 Axial plunger units (especially electromagnets) may be at risk of burning during and shortly after operation. | 3、Appropriate safety measures (such as wearing protective clothing) should be taken. - The characteristics of the axial plunger unit may vary with different working conditions (working pressure, oil temperature) of the axial plunger element, the characteristics may change. | 1、Oil nozzles and fixed threads are designed for maximum prescribed pressure. Machine or system manufacturers must ensure that the safety factor of connecting components and pipes meets the specified working conditions (pressure, flow, hydraulic oil, temperature). | 2、The data and instructions contained here must be followed. | ||||||
| Install bolts: | Thread holes in the axial plunger unit: | |||||||||
| For installation bolts with ISO metric threads in accordance with DIN 13 standard and with ASME B1.1 standard threads, we recommend that the tightening torque of each box be checked according to VDI 2230. | The maximum allowable tightening torque MG Max is the maximum value for the internal threaded holes and shall not exceed that value. | |||||||||
| · Connector: | Use the following tightening torque: | |||||||||
| Refer to manufacturer's instructions for tightening torque of the joints used. | ||||||||||
| · Locking screw: | ||||||||||
| For the metal locking screw attached to the axial plunger element, the fastening torque MV required for the locking screw is applied. For numerical values, see the table below. | ||||||||||
