1.Depth of drilling QTZ-2 drill rig machine popular mining machinery
- 100 Set / Sets per Month
- QINGDAO
- T/T L/C
- 30 days
You May Like
-
QTZ-3 Meet the requirement of soil sampling for 15-20 meters depth drilling rig popular rock core nachine
-
Stability power QTZ-3D electric soil sampling drilling work effiency core mining machine
-
Basis of SH30 exploration drilling rig work effiency core mining machine.
-
Rock drill equipped with conical clutch direct grouting drilling rig machine.
-
HZ-130YY drilling rig automatic feed mechanism with oil pressure core mine machine.
-
Working effiency equipped with ball card core borer machine XYX-130 wheeled hydraulic core drilling rig
Product Details
| Brand Name | Huaxia master | Place of Origin | China | |
| Model Number | QTZ-2 | Type | Core Drilling Rig | |
| Certification | ISO9001 | After-sales Service Provided | Overseas service center available | |
| Warranty | 6 months | Weight | 25kg | |
| Power Type | Gasoline | Voltage | 380/660v | |
| Usage | Coal | Condition | New |
Product Description
QTZ-2 soil sampling drilling rig
1. Brief introduction of QTZ-2 soil sampling drilling rig
QTZ-2 soil sampling drilling rig adopts the more power, and the impact force is stronger and the drilling depth is deeper, which can drill up to 10-15 meters.
2. Applications of QTZ-2 soil sampling drilling rig
· Geotechnical engineering investigation; environmental soil survey; agricultural soil survey.
· Groundwater survey; coastal geological survey; wetland environment investigation.
· Tailing pond investigation, archaeological investigation, physical chemistry and secondary halo sampling.
2. Technical parameters of QTZ-2 soil sampling drilling rig
QTZ-2 soil sampling drilling rig | ||
Power | power | 3.3HP |
lighter way | backflush pull rope | |
oil consumption | 0.55 l/h | |
Impact times | 1650r/min | |
Impact energy | 35J-65J | |
Core depth | 10m-15m | |
Host weight | 25kg | |
4.Configurations list of QTZ-2 soil sampling drilling rig
Item | Parameter | Platform | Quantity |
Soil sampling drilling rig | QTZ-2 | set | 1 |
Side buckle impact take over | 32*150 | pc | 1 |
Tapered tap | 32*80 | pc | 13 |
Drill pipe | 32*700 | pc | 13 |
Taper tap | 32*100 | pc | 13 |
Reducing nipple | 32*50 | pc | 1 |
Collar | 50*150 | pc | 1 |
Open tube | 50*600 | pc | 1 |
Double-edged pipe boots | 50*100 | pc | 2 |
Reducing nipple | 32*70 | pc | 1 |
Collar | 70*150 | pc | 1 |
Open tube | 70*600 | pc | 1 |
Inner edge pipe boots | 70*100 | pc | 1 |
Outer edge pipe boots | 70*100 | pc | 1 |
Portable sounding hammer | 10kg | pc | 1 |
Sounding the reducing nipple | 32 | pc | 1 |
Double sided hand | 32 | pc | 1 |
Touch probe | 32 | pc | 1 |
Puller | three force arm | set | 1 |
The ratio of oil | 25:1 | pc | 1 |
Oil funnel | pc | 1 | |
Pipe wrench | 80mm | hold | 1 |
Special internal six party | multi-function | 1 | |
Wrench | 24/27 | 1 | |
Internal six party | #6 | 1 | |
Six prismatic wrench | 1 | ||
Spark plug wrench | 1 | ||
Screw driver | 1 | ||
Spare spark plug | 1 |
