NISSAN Wheel Bearing VKBA7608

A.B.S.

201591

ASHIKA

44-21035

ASHUKI

N796-34

BENDIX

051137B

BLUE PRINT

ADN18373

FAG

713 6139 90

FENOX

WHB83170

HERTH+BUSS JAKOPARTS

J4711063

JAPANPARTS

KK-21035

JAPKO

421035

KAMOKA

5500094

KAVO PARTS

WBH-6538

KAWE

FR951195

LYNXAUTO

WH-1073

MAGNETI MARELLI

600000139390

MDR

MWB-R1035

MOOG

NI-WB-11990

NIPPARTS

N4711076

NK

762242

OPTIMAL

962206

PATRON

PBK4017H

PFI

PHU2386

SAKURA

4104108

SBS

1401762242

SNR

R168.78

SPIDAN

27802

TRISCAN

8530 14253

NISSAN

CUBE (Z12)

2010-

NISSAN

TIIDA (C11)

2007-2011

NISSAN

TIIDA (SC11X)

2007-2012

Bolt Circle Diameter A

4.5000 in

Bolt Circle Diameter B

3.6220 in

Brake Pilot Diameter

2.6771 in

Hub Pilot Diameter

2.7165 in

Bolt Hole Size

M10X1.25

Bolt Size

M12X1.25

Flange Diameter

5.8267 in

Flange Offset

2.7165 in

Sensor Ring

YES

Number of Bolts

4

Number of Holes

4

Wheel Pilot Diameter

2.5984 in

Steel Ball

GCr15 GB/T18254

Inner Ring

GCr15 GB/T18254

Outer Ring

65Mn GB/T1222

Flange

55# GB/T699

Steel Ball Hardness

HRC61-65

Raceway Hardness

HRC60-64

Inner Ring Hardness

HRC60-65

Outer Ring Hardness

HRC58-62

Flange Hardness

HRC58-62

      Wheel hub are ground by diamond rollers. We make sure each product's grinding time is more than 90 seconds, so as to improve auto parts Wheel hub accuracy and quality's stability. Wheel hub are 100% inspected, and the pass rate is over 99.5%. Warranty period is 50,000 kilometers per year.
